G1129 base type ii – Grizzly G1129 User Manual
Page 35
REF#
PART#
DESCRIPTION
REF#
PART#
DESCRIPTION
G1128/G1129 Power Feeders
-33-
010 P1128101
HANDLE ASSEMBLY
020 P1128102
HAND WHEEL
021 P1128021-1 HAND WHEEL
030 PRP31M
ROLL PIN 6 x 36
040 P1128104
BUSHING
060 P1128060-1 COLUMN CAP
070 PSS04M
SETSCREW M6-1.0 X 12
080 P1129080
ELEVATING SCREW
100 P1128110
ELEVATING KEY
120 PSB04M
CAP SCREW M6-1.0 X 10
130 PSB50M
CAP SCREW M5-0.8 X 10
140 P1129140
HORIZONTAL COLUMN
150 P1129150
RACK
160 P1129160
ELEVATING BRACKET
170 P1128170
PINION
180 P1128180
SPECIAL SETSCREW
190 P1129190
VERTICAL COLUMN
200 P1128120
HANDLE ASSEMBLY
201 P1128120-1 HANDLE
202 P1128120-2 HANDLE BODY
203 P1128120-3 BALL
204 P1128120-4 SPRING
205 PSS17M
SETSCREW M8 - 1.25 X 6
210 PW06M
FLAT WASHER 12MM
220 P1128122
STUD
221 P1129221-1 STUD
230 G1137
BASE
240 PB33M
HEX BOLT M12 - 1.75 X 50
250 PLW05M
LOCK WASHER 12MM
261 P1128126-1 HANDLE BODY
270 PRP07M
ROLL PIN 6 X 20
280 P1129128
HORIZONTAL BRACKET
290 P1128129
LOCK STUD
300 P1129130
SWIVEL CASTING
310 P1129131
MOTOR CLAMP
320 PB22M
HEX BOLT
330 P1128122
STUD
340 PN01M
HEX NUT M6-1.0
G1129 Base Type II
