REF# PART# DESCRIPTION REF# PART# DESCRIPTION
G1128/G1129 Power Feeders -21-
05 P1128005 FRAME
07 P1128007 OIL CAP
08 P1128008 O-RING
09 P1128009 BUSHING
10 P1128010 WORM GEAR SHAFT
10-1 P1128010-1 SHAFT
11
P1128011 WORM GEAR 30T
12 PR10M SNAP RING 22mm
14 P1128014 O-RING
15 P1128015 COVER
16 PFH05M FLAT HD SCR M5-0.8 x 12
17 P1128017 OIL SEAL 17 - 32 - 7
18 P1128018 GEAR 30T
19 PW04M FLAT WASHER 10mm
20 PN02M HEX NUT M10 - 1.5
21 P1128021 COVER
22 P1128022 KNOB
23 PK46M KEY 6 x 6 x 8mm
27 P1128027 BUSHING
48 P1128048 GEAR 20T
49 P1128049 CHAIN 11 LINKS
50A P1128050A SPROCKET 12T
50B P1128050B SPROCKET 12T
50-1 P1128050-1 SPROCKET 10T
51
P1128051 CHAIN 18 LINKS
51-1 P1128051-1 CHAIN 16 LINKS
52
PR05M SNAP RING 15mm
53A P1128053A SPROCKET 12T
53B P1128053B SPROCKET 12T
53-1 P1128053-1 SPROCKET 20T
54
PR17M SNAP RING 26mm
55 P1128055 TUBE/BUSHING
56 P1128056 GREASE FITTING
57 P1128057 ROLLER STAND
59 P1128059 SPRING
60 P1128060 SPROCKET/SHAFT
61 P1128061 SPROCKET/SHAFT
65 PN03M HEX NUT M8 - 1.25
66 PLN04M LOCK WASHER 8mm
67 PR09M SNAP RING 20mm
68 P1128068 CHAIN 9 LINKS
69 P1128069 SPROCKET 13T
70 P1128070 ROLLER SUPPORT
71 P1128071 SHAFT
72 P1128072 COVER
73 P1128073 FEED ROLLER
73-2 P1128073-2 FEED ROLLER MOUNT
73-3 PSB01M
CAP SCREW M6 - 1.0 x 16
74 P1128074 STAR WASHER 8mm
75 PSB14M CAP SCREW M8 - 1.25 x 20
76 P1128076 SPACER
77 P1128077 GEAR 26T
78 P1128078 GEAR 24T
81 PR01M SNAP RING 10mm
82 P1148082 SPACER
G1128 Gear Box
