Side 11, 400c – Garmin 400C User Manual
Page 17
Fishfinder 400C betjeningsvejledning
S
ådan
InStallerer
du
F
IShFInder
400C
Jævnstrømkilde
Til transducer
(Rød) + DVC
(Sort) Jord
(Blå) NMEA-ud
(Grøn) CANet L
(Hvid) CANet H
(Gul) Alarm lav
NMEA-enhed
Alarmrelæ
Maks. 100 mA
kollektorstrøm
Fishfinder 400C Ledningsnet
PIN 8 - Sort (jord)
PIN 13 - R
ød
(positiv j
ævnstrøm)
PIN 7 - Gui (alarm)
PIN 12 - Hvid (CANet H)
PIN 16 - Gr
øn (CANet L)
PIN 18 - Blå (NMEA-out)
Fishfinder 400C Ben-tildeling
