Model G0466/G0469 Air Compressors

-

25

-

G0466 Parts List

REF PART #

DESCRIPTION

REF PART #

DESCRIPTION

1

PSB07M

CAP SCREW M6-1 X 30

44

PN06M

HEX NUT M5-.8

2

PLW03M

LOCK WASHER 6MM

45

P0466045

CENTRIFIGAL SWITCH

3

P0466003

CYLINDER HEAD

46

PHTEK15M TAP SCREW M4 X 10

4

P0466004

EXHAUST ELBOW

47

PLW02M

LOCK WASHER 4MM

5

P0466005

HEAD GASKET

48

P0466048

FAN

6

P0466006

VALVE PLATE

49

P0466049

COVER

7

P0466007

VALVE REED

50

PB95M

HEX BOLT M5-.8 X 15

8

P0466008

VALVE PLATE GASKET

51

P0466051

HANDLE GRIP

9

P0466009

PISTON

51-1 P0466051-1 HANDLE

10

P0466010

UPPER CYLINDER GASKET

52

PHTEK5M

TAP SCREW M4 X 12

11

P0466011

CYLINDER

53

PSB48M

CAP SCREW M6-1 X 35

12

PSB02M

CAP SCREW M6-1 X 20

54

P0466054

CAP SCREW M6-1 X 95

13

P0466013

LOWER CYLINDER GASKET

55

P0466055

SLEEVE

14

P0466014

COMPRESSION RING

56

P0466056

SLEEVE

15

P0466015

OIL SCRAPER RING

57

P0466057

QUICK CONNECT-FEMALE

16

P0466016

PISTON PIN

58

P0466058

REGULATOR

17

PR03M

EXT RETAINING RING 12MM

59

P0466059

PRESSURE GAUGE

18

P0466018

CONNECTING ROD

60

P0466060

SAFETY VALVE

19

P0466019

ECCENTRIC

61

P0466061

PRESSURE GAUGE

20

PN01M

HEX NUT M6-1

62

P0466062

STRAIN RELIEF

21

P0466021

OIL FILL CAP

63

P0466063

PRESSURE SWITCH

22

P0466022

HEX BOLT M5-.8 X 155

64

P0466064

CONNECT NPT 1/4

23

PW02M

FLAT WASHER 5MM

65

P0466065

CONNECT NPT 1/4

24

P0466024

OIL SIGHT GAUGE

66

P0466066

PRESSURE RELIEF TUBE

25

P0466025

OIL SIGHT GAUGE SEAL

67

P0466067

COMPRESSION NUT

26

P0466026

CRANKCASE COVER

68

P0466068

POWER CORD 14GA

27

P0466027

COVER GASKET

69

P0466069

CABLE CONNECTOR (O)

28

P0466028

OIL SEAL

70

P0466070

CABLE CONNECTOR (U)

29

P0466029

CRANKCASE

71

P0466071

CABLE CONNECTOR (O)

30

P0466030

CAPACITOR 200MFD 125VAC

72

P0466072

MOTOR COVER

31

P0466031

CAPACITOR 40 MFD 250VAC

73

P0466073

TANK

32

PN03M

HEX NUT M8-1.25

74

P0466074

CHECK VALVE

33

PW01M

FLAT WASHER 8MM

75

P0466075

DRAIN VALVE NPT 1/4

34

PLW09M

LOCK WASHER 3MM

76

P0466076

RUBBER FOOT

35

PS12M

PHLP HD SCR M3-.5 X 6

77

PB09M

HEX BOLT M8-1.25 X 20

36

P0466036

WAVY WASHER 17MM

78

PW01M

FLAT WASHER 8MM

37

P6203

BALL BEARING 6203

79

PB07M

HEX BOLT M8-1.25 X 25

38

PR18M

EXT RETAINING RING 17MM

80

P0466080

OUTLET TUBE 10MM

39

P0466039

ROTOR

81

P0466081

FIN TUBING

40

P6004

BALL BEARING 6004

82

P0466082

EXHAUST NUT

41

P0466041

STATOR

83

PW04M

FLAT WASHER 10MM

42

P0466042

REAR MOTOR COVER

84

P0466084

AIR FILTER KIT

43

PLW01M

LOCK WASHER 5MM
