Introduction
English
- 5 -
Chapter 1 Introduction
Features Summary
Motherboard y 8S648FXP-RZ or 8S648FXP-RZ-C
CPU y Socket 478 for Intel ® Pentium ® 4 (Northwood, Prescott) with HT Technology
y Intel ® Pentium ® 4 800/533/400MHz FSB
y 2nd cache depends on CPU
Chipset y Northbridge : SiS 648FX
y Southbridge : SiS 964
Memory y 3 184-pin DDR DIMM sockets, supports up to 3GB DRAM (Max)
y Supports DDR400/DDR333/DDR266 DIMM
y Supports up to 2 unbuffered DIMM DDR400
y Supports up to 3 unbuffered DIMM DDR333
y Supports only 2.5V DDR SDRAM
Slots y 1 AGP slot supports 8X/4X(1.5V) mode
y 5 PCI slots
IDE Connections y 2 IDE connections (Ultra DMA33/ATA66/ATA100/ATA133),
allows connection of 4 IDE devices
FDD Connections y 1 FDD connection, allows connection of 2 FDD devices
Onboard SATA y 2 Serial ATA ports from SiS 964 (SATA0, SATA1)
Peripherals y 1 Parallel port supporting Normal/EPP/ECP mode
y 2 Serial port (COMA, COMB)
y 8 USB 2.0/1.1 ports (rear x 4, front x 4 via cable)
y 1 front audio connector
y 1 PS/2 keyboard port
y 1 PS/2 mouse port
Onboard LAN* y Onboard ICS1883 chipset (10/100Mbit)*
y 1 RJ45 port*
Onboard Audio y ALC655 codec
y Supports 2/ 4/ 6 channel audio
y Line Out/ Line In/ Mic In connection
y SPDIF In/ Out
y CD In connector
I/O Control y IT8705
Hardware Monitor y System voltage detection
y CPU temperature detection
y CPU / System fan speed detection
Onboard SATA RAID y Onboard SiS 964 chipset (SATA0, SATA1)
y Supports data striping (RAID 0) or mirroring (RAID 1) function
y Supports data transfer rate of up 150MB
y Supports a maximum of 2 SATA connections
BIOS y Use of licensed AWARD BIOS
y Supports Q-Flash
Additional Features y Supports @BIOS
y Supports EasyTune
Form Factor y ATX form factor, 21cm x 29.5cm
"*" Only for 8S648FXP-RZ.
