Page 4
36" Wide Hood
Refer to Hood
Installation
Instructions
12" Min. to
Combustible
Material
Each Side
36" Min. to
Combustible
Material From
Cooking
Surface
13" Max.
7"
22-3/4" Min.
Electric/Gas
Supply
35"
1/2"
2"
Cooking Surface
18" Min.
2-1/2"
8"
22" High
Backsplash
with Shelf
26-5/8"
12"
36" Min.
to Combustibles
9-1/2"
3/4"
22"
12" High Backsplash
Allow Additional Clearance
Below the Cooktop Burner
Box for the Regulator and
Gas Connections
8-7/16"
26-5/8"
35-7/8"
48" Wide Models
36" Wide Models
48" Wide Hood
Refer to Hood
Installation
Instructions
18" Min.
12" Min. to
Combustible
Material
Each Side
36" Min. to
Combustible
Material From
Cooking
Surface
13" Max.
17"
22-3/4" Min.
Electric/Gas
Supply
46-1/8"
7/8"
2-1/2"
2"
Cooking Surface
8"
Mon
ogra
m
FRO
NT
REAR
HEA
TING
FRO
NT
REA
R
FRO
NT
REA
R
8-7/16"
26-5/8"
47-7/8"
Allow Additional Clearance
Below the Cooktop Burner
Box for the Regulator and
Gas Connections
36" Min.
to
Combustibles
0" Clearance
12" Min. to Combustibles or
0" Min. to Combustibles
with 12" or 22" Backsplash
4
PRODUCT DIMENSIONS AND CLEARANCES
Design Information
