Grizzly G0613/G0614 - Manual (Page 51)

G0613/14 Swivel Mast Metal Cutting Bandsaw
-49-
Parts List (G0613)
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PSB64M CAP SCREW M10-1.5 X 25 43 P0613043 HANDLE
2 PW04M FLAT WASHER 10MM 44 P0613044 HANDLE PIPE
3 P0613003 SHAFT 45 PSBS05M BUTTON HD CAP SCR M6-1 X 25
4 P0613004 ANCHOR BLOCK 46 PSS20M SET SCREW M8-1.25 X 8
5 PN13M HEX NUT M16-2 47 PSB40M CAP SCREW M8-1.25 X 35
6 P6204 BALL BEARING 6204 48 P0613048 BLADE ADJUSTMENT BAR
7 P0613007 BODY FRAME 49 PSB58M CAP SCREW M8-1.25 X 12
8 PN01M HEX NUT M6-1 50 PS09M PHLP HD SCR M5-.8 X 10
9 PB29M HEX BOLT M6-1 X 30 51 PW02M FLAT WASHER 5MM
10 P0613010 KNOB 52 P0613052 BLADE COVER (FRONT)
11 P0613011 BLADE TENSION HANDLE 53 P0613053 ADJUSTMENT BLOCK (FRONT)
12 P0613012 CONCAVE WASHER 53-1 P0613053-1 FLOW VALVE
13 P0613013 LEADSCREW 53-2 P0613053-2 COOLANT HOSE
14 PSB31M CAP SCREW M8-1.25 X 25 53-3 P0613053-2 STEEL "T"
15 P0613015 FIXED BLOCK 54 P0613054 ECCENTRIC GUIDE (L)
16 PSB13M CAP SCREW M8-1.25 X 30 55 P608A BALL BEARING 608
17 PLW04M LOCK WASHER 8MM 57 PR09M EXT RETAINING RING 20MM
18 P0613018 REDUCER BLOCK 58 P0613058 ECCENTRIC GUIDE (R)
19 PW01M FLAT WASHER 8MM 59 PLW04M LOCK WASHER 8MM
20 PSB31M CAP SCREW M8-1.25 X 25 60 PN03M HEX NUT M8-1.25
21 P0613021 GEARBOX 62 PSB13M CAP SCREW M8-1.25 X 30
22 P0613022 MOTOR 220V, SINGLE PHASE 63 PW01M FLAT WASHER 8MM
22-1 P0613022-1 START CAPACITOR 64 P0613064 ADJUSTMENT BLOCK (REAR)
22-2 P0613022-2 RUN CAPACITOR 65 P4030007 PIN
22-3 P0613022-3 FAN 66 P608A BALL BEARING 608
22-4 P0613022-4 FAN COVER 67 P0613067 CHIP PLATE
25 PB32M HEX BOLT M10-1.5 X 25 68 PW02M FLAT WASHER 5MM
26 PW04M FLAT WASHER 10MM 69 PS09M PHLP HD SCR M5-.8 X 10
27 P0613027 KEY 8 X 7 X 35 70 P0613070 DRIVE WHEEL
28 P0613028 OUTPUT SHAFT 71 PW04M FLAT WASHER 10MM
29 PK109M KEY 7 X 7 X 35 72 PB32M HEX BOLT M10-1.5 X 25
30 P6206 BALL BEARING 6206 73 P0613073 WATERPROOF LIMIT SWITCH
31 P0613031 SPRING SUPPORT 73-1 P0613073-1 SWITCH BRACKET
32 P0613032 TENSION SPRING 73-2 PS09M PHLP HD SCR M5-.8 X 10
33 PSB06M CAP SCREW M6-1 X 25 73-3 PS75M PHLP HD SCR M5-.8 X 35
34 PLW03M LOCK WASHER 6MM 73-4 P0613073-4 WATERPROOF POWER CORD
35 P0613035 FRAME PIVOT SHAFT 74 P0613074 MAIN BLADE COVER
36 P0613036 CHIP COVER 75 PW03M FLAT WASHER 6MM
37 P0613037 TAPERED BEARING 32006 76 P0613076 KNOB SCREW M6-1 X 10
38 P0613038 BLADE COVER(REAR) 77 P0613077 SAW BLADE
39 P0613039 KNOB BOLT 3/8-24 X 1 78 P0613078 IDLER WHEEL
40 P0613040 FIXED BLOCK 79 PR11M EXT RETAINING RING 25MM
41 PSS06M SET SCREW M8-1.25 X 16
