29

MAC Address

The device ID, in HEX format. This is a very important ID for ISP
troubleshooting.

IP Address

This field shows LAN IP address of BudgeTone 200

Product Model

This field contains the product model info.

Software Version

• Program: This is the main software release, its number is always used for

firmware upgrade.

• Bootloader: This is normally not changed.

System Up Time

This field shows system up time since the last reboot.

Registered

This field indicates whether the device is registered to the SIP server(s).

PPPoE Link Up

This field shows whether the PPPoE connection is up if connected to DSL
modem.

Detected NAT Type This field shows what kind NAT the BudgeTone 200 is connected to via its LAN

port. It is based on STUN protocol.

5.2.3 Advanced User Configuration

To login to the Advanced User Configuration page, please follow the instructions in
section 5.2.1 to get to the following login page. The password is case sensitive with a
maximum length of 25 characters and the factory default password for Advanced User is
“admin”.

Grandstream Device Configuration

Password

Login

All Rights Reserved Grandstream Networks, Inc. 2004
