308-489 11
PARTS LIST
800–062 & 800–063 Hydra–Clean r 2245 Pressure Washer
REF PART
NO. NO. DESCRIPTION QTY
REF PART
NO. NO. DESCRIPTION QTY
1 801–494 ENGINE, 11 HP, Briggs &
Stratton I/C (For 800–063 only) 1
801–283 ENGINE, 11 HP, Wisconsin
Robin (For 800–062 only) 1
2 800–326 PUMP ASSEMBLY, 2200 psi
(see page 18) 1
3 800–067 CHASSIS 1
4 801–539 BUMPER 1
5 801–541 HANDLE 1
6 801–556 AXLE 1
7 801–550 WHEEL & TIRE ASSEMBLY 2
8 800–160 FRONT LEG ASSEMBLY 1
9 801–531 SCREW, Cap, hex hd 3/8–16 x 7 1
10 801–015 WASHER, Flat 1
11 801–499 NUT, Lock 3/8–16 1
12 801–537 LEG, Front 1
13 801–506 BOOT 1
14 801–504 BUMPER, Rubber 1
15 801–505 RETAINER, Spring 1
16 801–593 SPRING 1
17 801–521 BRACKET, Rail Stiffener 1
18 802–016 PLATE, Rail Stiffener 1
19 800–375 HOSE ASSEMBLY, w/couplers 1
20 801–571 HOSE, High Pressure 50’ 1
21 801–568 COUPLER, Male 3/8 1
22 801–569 COUPLER, Female 3/8 1
23 800–135 TIP ASSEMBLY, 0 Degree 1
24 801–090 COUPLER, Male 1/4 1
25 801–665 TIP, 0 Degree 1
26 800–134 TIP ASSEMBLY, 15 Degree 1
27 801–666 TIP, 15 Degree 1
28 800–060 TIP ASSEMBLY, 25 Degree 1
29 801–552 TIP, 25 Degree 1
30 800–061 TIP ASSEMBLY, 40 Degree 1
31 801–553 TIP, 40 Degree 1
32 801–548 GROMMET, Rubber 5
33 800–392 GUN & WAND ASSEMBLY 1
34 803–350 GUN, Spray 1
35 801–134 WAND, 32” 1
36 801–009 COUPLER, Female 1/4 1
37 801–569 COUPLER, Female 3/8 1
38 801–603 NIPPLE, Hex 3/8 1
39 801–674 SLEEVE, 28” 1
41 801–364 COVER, Belt Guard 1
42 801–500 BASEPLATE, Belt Guard 1
43 801–004 PULLEY, Pump 1
44 801–135 HUB, Pump 1
45 801–896 PULLEY, Engine 1
46 801–898 HUB, Engine (For 800–063 only) 1
801–376 HUB, Engine (For 800–062 only) 1
47 801–137 KEY 1
48 801–285 BELT, Drive (For 800–063 only) 2
801–003 BELT, Drive (For 800–062 only) 2
49 803–076 BUMPER, Rubber (For 800–062 only) 2
801–731 BUMPER, Rubber (For 800–063 only) 2
50 801–543 LABEL, Graco 1
51 802–363 LABEL, Caution 1
52 802–381 LABEL, Warning, ventilation 1
53 801–141 LABEL, Warning, belt guard 1
54 801–129 LABEL, Warning, chassis 1
55 801–130 LABEL, Warning, chassis 1
56 801–724 LABEL, Model 2245 1
57 801–941 SCREW, Cap, hex hd
5/16–18 x 1 7
58 801–940 SCREW, Cap, hex hd
5/16–18 x 3/4 1
60 801–559 SCREW, Cap, hex hd M8 x 30 4
61 801–022 SCREW, Cap, hex hd
5/16–18 x 1-3/4 4
62 803–298 SCREW, Cap, hex hd
5/16–18 x 3-1/2 1
63 801–546 SCREW, Cap, hex hd
3/8–16 x 1-1/4 4
64 801–605 SCREW, Machine, hex hd
#10–24 x 3/4 1
65 801–015 WASHER, Flat 3/8 4
66 801–023 WASHER, Flat 5/16 20
67 801–606 WASHER, Flat #10 1
68 801–363 WASHER, Lock 3/8 4
69 801–025 WASHER, Lock 5/16 20
70 801–875 WASHER, Lock #10 1
71 801–024 NUT, Hex 5/16–18 7
72 801–020 NUT, Lock 1/2–13 2
73 801–922 NUT, Flange 5/16–18 3
74 800–156 NUT, Flange 5/16–18 1
75 801–612 WASHER, Flat 1/2 2
76 801–608 PIN, Roll 3/16 x 1/2 1
77 801–610 BRACKET, Bumper 1
78 801–367 BUMPER, Rubber 1
79 801–676 SPACER, Pump 4
80 803–246 GUARD, Muffler (For 800–063 only) 1
81 802–521 O–RING, Female Coupler 3/8 1
82 801–202 O–RING, Female Coupler 1/4 1
