ITEM PART NO. QTY. DESCRIPTION
1 0E9947 1 RADIATOR R-IN,L-OUT 658X489X49
2 0E6340 1 VENTURI 3.0L FORD HSB
3 0E8531 2 SIDE SUPPORT RADIATOR HSB
4 0E6398 1 TUBE LOWER RAD 3.0L FORD HSB
5 0E6397 1 HOSE UPPER RAD 3.0LFORD HSB
6 080713 1 BRACKET COOLANT TANK
7 076749 1 TANK COOLANT RECOVERY
8 049814 4 SCREW HHC M10-1.5 X 25 G8.8
9 022131 8 WASHER FLAT 3/8-M10 ZINC
10 046526 4 WASHER LOCK M10
11 045772 4 NUT HEX M10-1.5 G8 YEL CHR
12 035685 4 CLAMP HOSE #28 1.32-2.25
13 0E8562 1 FAN GUARD HSB
14 058443 4 SCREW CRIMPTITE 1/4-20 X 5/8
15 0C2454 9 SCREW TH-FRM M6-1 X 16 N WA Z/JS
17 048031C 1 CLAMP HOSE BAND 1/4
18 029032 1 HOSE 9/32 ID (30" LG)
20 046627 1 CAP RADIATOR
21 069811 1 CAP HEX 1/4 NPT BRASS
22 065852 1 SPRING CLIP HOLDER .37-.62
23 0A2111 1 SCREW SWAGE 10-32 X 5/16 Z/YC
24 052250 2 TAPE FOAM 1 X 1 (27" LG)
25 035461 1 BARBED STR 1/4 NPT X 3/8
26 0C7649 1 CLAMP HOSE .38-.87
27 069860C 1 HOSE OIL DRAIN ASSY 21"
Section 9 - Exploded Views and Parts
Guardian Liquid-cooled 27 kW and 30 kW Generators
Radiator — Drawing No. 0E8528-B
