3307568 User’s Manual Hardware Setup
2.3
2.3.1
Connector
Function
Remark
CPU
LGA775 CPU socket
DDRIIA/B
240 -pin DDR2 SDRAM DIMM socket
FDD
34-pin floppy connector
CN_LPT
13 x 2-pin LPT connector
S_ATAII1/2/3/4/5/6 7-pin Serial ATA II connector
CN_12V
8-pin +12V additional power supply connector
CN_AUDIO
5
x
2-pin
audio
connector
CDIN
4-pin CD-ROM audio input connector
CN_PS
3-pin ATX function connector
DC_IN
4-pin power supply connector
CN_DIO
6 x 2-pin digital I/O connector
CN_USB1/2/3
10-pin
USB
connector
CPUFAN
4-pin CPU cooler fan connector
SYSFAN
3-pin system cooler fan connector
NBFAN
3-pin Northbridge cooler fan connector
CN_IR
5-pin IrDA connector
CN_ATKB
5-pin AT keyboard connector
CN_INV
5-pin LCD inverter connector
3307568XG
CN_LVDS
20 x 2-pin LVDS connector
3307568XG
JFRNT
14-pin front panel switch/indicator connector
Mini-PCI
1 x 124-pin Mini-PCI socket
CN_DVI 26-Pin connector
3307568DG
CN_COM1/2
5
x
2-pin
com
connector
2.3.2
Connector
Function
Remark
CRT
DB15 VGA connector
RJ45_1/2
One
RJ45
LAN
connector
PS2
PS/2 keyboard and mouse connector
14
Connector Reference
