Gold's Gym Platinum GGBE0957.0 - Manual (Page 8)

8
5
11
9
24
24
28
6
10
28
28
21
7
28
22
6
13
24
5. Attach the Backrest (11) to the Backrest Tubes
(9) with four M6 x 55mm Screws (24) and four M6
Washers (28).
Do not tighten the Screws yet.
Then, attach the Headrest (10) with two M6 x
55mm Screws (24) and two M6 Washers (28).
Do
not tighten the Screws yet.
6. Attach the Seat (13) and the Seat Carriage (7)
to the Seat Frame (6) with two M6 x 20mm
Screws (21), two M6 x 40mm Screws (22), and
two M6 Washers (28).
