g0665 slow speed Cold Cut saw
-21-
blade Changes
4. remove the arbor cap screw. it has left-hand
threads and loosens when turned clockwise.
(see
figure 29).
5. remove the blade and blade flange (figure
28).
figure 30. Blade removed.
6. place the blade flange on the new blade, as
shown in figure 31.
figure 31. installing new blade.
The teeth of saw blades
are sharp and can easily
cut fingers and hands.
Always wear heavy leath-
er gloves when handling
saw blades.
To replace the blade:
1. disConneCt sAW FroM poWer!
2. disconnect the blade guard linkage by remov-
ing the cap screw that connects it to the saw
guard (
figure 28).
3. rotate the blade guard and linkage out of the
way, as shown in figure 29.
figure 29. exposing blade.
figure 28. removing guard linkage.
Cap screw
Blade guard
linkage
Blade guard
linkage
Blade Flange
Blade
Blade Flange
Blade
Arbor Cap screw
