-34- G8622 Tilting Spindle Sliding Table Shaper
Design Type...................................................................................................... Floor Model
Overall Dimensions:
Fixed Table ..............................................................................................35 1 ⁄
2
'' x 14 7 ⁄
8
"
Sliding Table..............................................................................................35 1 ⁄
2
" x 13 1 ⁄
4
"
Height (Includes Fence) ........................................................................................45 1 ⁄
2
"
Height From Table To Floor ..................................................................................34 3 ⁄
4
''
Length (w/ Knob On) ............................................................................................42 1 ⁄
2
''
Width......................................................................................................................35 1 ⁄
2
''
Width w/ Table Extended ......................................................................................56 1 ⁄
2
''
Footprint ......................................................................................................27" x 25 1 ⁄
2
"
Shipping Weight ................................................................................................720 lbs.
Capacities:
Spindle Sizes .............................................................................................. 3 ⁄
4
'', 1'', 1 1 ⁄
4
''
Spindle Lengths ..................................................................................................6'' - 7''
Spindle Capacity Under Nut ..................................................................4
1 ⁄
4
'', 4 5 ⁄
8
'', 5 1 ⁄
8
''
Spindle Travel..........................................................................................................3 1 ⁄
4
''
Dust Port ....................................................................................................................4"
Table Counter-bore ............................................................................................7'' x
5 ⁄
8
''
Max. Cutter Diameter ..............................................................................................5 7 ⁄
8
''
Spindle Speeds ........................................................3600, 5100, 8000, 10,000 R.P.M.
Spindle Tilt ........................................................................................................0° - 45°
Construction:
Table ..................................................................................................Ground Cast Iron
Fence Assembly ............................Cast Iron / Wood; Independently Micro-Adjustable
Miter Fence ....................................................................................Extruded Aluminum
Body Assembly ..............................................................................................Cast Iron
Cabinet ....................................................................................................Formed Steel
Motor:
Type ............................................................................TEFC Capacitor-Start Induction
Horsepower..........................................................................................................5 H.P.
Phase ⁄ Voltage ............................................................................Single Phase ⁄ 220 V
Amps ......................................................................................................................14 A
Switch ..............Push Button ON/OFF, Emergency Stop; Lever for Forward / Reverse
Cycle ⁄ R.P.M.............................................................................60 Hertz ⁄ 3450 R.P.M.
Bearings ............................................................Shielded & Lubricated Ball Bearings
Features:
..................................................................................Lever Actuated Stock Hold-Down
..................................................................Miter Angle Adjustable 60˚ Left to 60˚ Right
................................................................................Miter Fence Adjustable Stop Block
..........................................................................4 Spring Steel Hold-down Assemblies
..............Fence Adjustments Include Built-In Ratchets And Knob-Equipped Adjusters
..............................................................................................................3 Table Inserts
..............................................................................Spindles Include Spacers And Nuts
......................................................................Spindle Height Scale In Inches And MM
..........................Sliding Table Rides On Eight Shielded And Lubricated Ball Bearings
Specifications, while deemed accurate, are not guaranteed.
Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
GRIZZLY MODEL G8622 TILTING SPINDLE
SLIDING TABLE SHAPER
MACHINE DATA
SHEET
