800 Series Coffee Grinders Page 9
ITEM # DESCRIPTION
810 810 TALL 835 875 890 865
2 Washer, #8 internal tooth
*3 Top,800 series sanitation *
*4 Lid, 800 series sanitation *
5 Screw, #8 x 1/4 ph truss hd 86875 86875 86875 86875 86875 86875
*6 Lid, bifold hinge *
*7 Top, bifold lid *
8 Hopper 83356
9 Finger guard
10 Gasket, hopper
11 Screw, # 8-32 x 3/8"slotted ovl
12 Plate, knob retainer
13 Knob, grind select
14 Pointer, knob
15 Screw, # 6-32 x 1/4"
16 Plate, detent
17 Screw, # 8-32 x 1/4"
18 Screw, grind adjust
19 Pin, grind adjust
20 Screw, 5/16-18 x 1" lg.
21 Grind cap
22 Plunger, detent
23 Spring, detent
24 Knob. Lid
*25 Front panel * 83316 * 83316 * 83301 * 83363 * 83363 * 83301
26 Cover, shear
27 Disc, shear
28 Drive, shear ------------ ------------
29 Feedworm
30 Burr set
31 Screw, #10-32 x 5/16"
32 Tension spring
33 Thrust collar
34 Grind head
35 Motor, 1/2 hp 230VAC 60 Hz
36 Nut, 1/4-20 cage
37 Screw, chaff spring
38 Chaff spring
39 Spout 80088
40 Screw, # 8-32 x 3/8" lg
41 Spout flap ------------ ------------
42 Screw, spout flap ------------ ------------
43 motor shelf
44 Bolt, 1/4-20 x 5/8
45 Capacitor, 115 Vac 60 Hz
46 Screw, 8-32 x 3/8"
47 Relay, 115 VAC ------------ ------------
48 Screw, 8-32 x 1/4"
50 Screw, 8-32 x 1 1/4" lg ------------ ------------ ------------ ------------ ------------ ------------
51 Relay, Motor Start, 230V
52 Screw, 6-32 x 1/4"
53 Circuit breaker, 5 amp for 230vac
*54 Casing, grocery * 83332* 70553* 83332* 83362* 83362* 70553*
55 Power cord, 1.5MM CE
56 Strain relief, standard cord
57 Screw, # 10 x 1/2"
*58 Base*
59 Tidy tray cover ------------ ------------
60 Tidy tray drawer ------------ ------------
*61 Lower front* 83305 83299 80072
62 Switch, micro ------------ ------------
64 Hole plug ------------ ------------ 83737 ------------ ------------ ------------
68 Nut, 8-32 KEPS ------------ ------------ 86810 ------------ ------------ ------------
66 Bag actuator ------------ ------------ 80068
67 Bracket, switch ------------ ------------
75 Switch, start 70449 70449 70445 88056 88056 70445
76 Switch, stop ------------ ------------ 83327 88057 88057 83327
78 Platform, bag ------------ 85252 ------------ ------------ ------------ ------------
79 Pin, roll ------------ 83779 ------------ ------------
80 Screw, 4-40 x 5/8" sl bd hd ------------ ------------
81 Nut, 4-40 hex ------------ ------------
82 Bushing, Flanged ------------ ------------
83 Bushiing, Spacer ------------ ------------
84 Harness, wiring 120 vac 83341 83341
79 Harness, bag switch ------------ ------------
88 Eylet, 0.162 I.D. Rolled Flange ------------ ------------
89 Feedworm spring ------------ ------------ ------------ ------------
230V GROCERY GRINDER PART NUMBERS FOR THESE MODELS:
83324
88211
86914
82024
82022
88027
86866
83361 82025
86224
82023K 86434
86110
86887
82021 86439
83318
83443
86223
86355 (70483 for Sanitary Models)
86123 86620
86154
85188K 86468
85281WK 86430
86812
86118 86438
86304 86428
84171S 84172 86435
86421 86580
86864
07009-02 86806
84154 82026
88033 82019
86807
82036
86993
83334
86872
86179
86874
83106
83247
83107
83248
86071
86868
83302* 83321*
83308R and 83308B - all models
83356 88280
86929
80084
83250
86620
86928
83322
83323
86822
83451RK and 83451BK - all models
83450RK and 83450BK - all models
88704RK and 88704BK - all models
80086
82039
86432
86424
83252
83253
82029
82014K
80083
61453
800 Series Parts List - 230V
