Page 8 800 Series Coffee Grinders
ITEM # DESCRIPTION 120V GROCERY GRINDER PART NUMBERS FOR THESE MODELS:
810 810A 810 TALL 835 875 890 865
2 Washer, #8 internal tooth
*3 Top,800 series sanitation *
*4 Lid, 800 series sanitation *
5 Screw, #8 x 1/4 ph truss hd 86875 86875 86875 86875 86875 86875 86875
*6 Lid, bifold hinge *
*7 Top, bifold lid *
8 Hopper 83356
9 Finger guard
10 Gasket, hopper
11 Screw, # 8-32 x 3/8"slotted ovl
12 Plate, knob retainer
13 Knob, grind select
14 Pointer, knob
15 Screw, # 6-32 x 1/4"
16 Plate, detent
17 Screw, # 8-32 x 1/4"
18 Screw, grind adjust
19 Pin, grind adjust
20 Screw, 5/16-18 x 1" lg.
21 Grind cap
22 Plunger, detent
23 Spring, detent
24 Knob. Lid
*25 Front panel * 83316 * 83301 83316 * 83301 * 83363 * 83363 * 83301
26 Cover, shear
27 Disc, shear
28 Drive, shear ------------ ------------
29 Feedworm
30 Burr set
31 Screw, #10-32 x 5/16"
32 Tension spring
33 Thrust collar
34 Grind head
35 Motor, 1/2 hp 115VAC 60 Hz
36 Nut, 1/4-20 cage
37 Screw, chaff spring
38 Chaff spring
39 Spout 80088
40 Screw, # 8-32 x 3/8" lg
41 Spout flap ------------ ------------ ------------
42 Screw, spout flap ------------ ------------ ------------
43 motor shelf
44 Bolt, 1/4-20 x 5/8
45 Capacitor, 115 Vac 60 Hz
46 Screw, 8-32 x 3/8"
47 Relay, 115 VAC ------------ ------------ ------------
48 Screw, 8-32 x 1/4"
49 Timer, 115VAC 90 sec. ------------ 86449 ------------ ------------ ------------ ------------ ------------
50 Screw, 8-32 x 1 1/4" lg ------------ 86791 ------------ ------------ ------------ ------------ ------------
53 Circuit breaker,10 amp for 115vac
*54 Casing, grocery * 83332* 83332* 70553* 83332* 83362* 83362* 70553*
55 Power cord, standard 115vac
56 Strain relief, standard cord
57 Screw, # 10 x 1/2"
*58 Base*
59 Tidy tray cover ------------ ------------ ------------
60 Tidy tray drawer ------------ ------------ ------------
*61 Lower front* 83305 83305 83299 80072
62 Switch, micro ------------ ------------ ------------
64 Hole plug ------------ ------------ ------------ 83737 ------------ ------------ ------------
68 Nut, 8-32 KEPS ------------ ------------ ------------ 86810 ------------ ------------ ------------
66 Bag actuator ------------ ------------ ------------ 80068
67 Bracket, switch ------------ ------------ ------------
75 Switch, start 70449 70445 70449 70445 88056 88056 70445
76 Switch, stop ------------ 83327 ------------ 83327 88057 88057 83327
78 Platform, bag ------------ ------------ 85252 ------------ ------------ ------------ ------------
79 Pin, roll ------------ ------------ 83779 ------------ ------------
80 Screw, 4-40 x 5/8" sl bd hd ------------ ------------ ------------
81 Nut, 4-40 hex ------------ ------------ ------------
82 Bushing, Flanged ------------ ------------ ------------
83 Bushiing, Spacer ------------ ------------ ------------
84 Harness, wiring 120 vac 83341 83333 83341
79 Harness, bag switch ------------ ------------ ------------
88 Eylet, 0.162 I.D. Rolled Flange ------------ ------------ ------------
89 Feedworm spring ------------ ------------ ------------ ------------ ------------
84171S
86581 86419
85303
88033 82019
82036
86993
83334
86872
86434 82023K
86439 82021
86110
88280 83356
82025 83361
82022
88027
86866
83451RK and 83451BK - all models
83450RK and 83450BK - all models
88704RK and 88704BK - all models
83308R and 83308B - all models
85188K
86355 (70483 for Sanitary Models)
86123
86154
86620
86468
86224
83324
88211
86914
82024
82026
85281WK
86812
86118
86304 86438
86430
86428
86435
84172
86822
86807
86223
83443
83318
86887
86864
07009-02 86806
84154
86144
83247
86618
86222
86874
86071
83302* 83321*
83323
83322
86868
82014K
80084
86620
86928
83250
80083
82039
86432
86929
83252
83253
80086
82029
800 Series Parts List - 120V
