28
Deluxe Vane Axial Heater
Control Box Parts
HEATER PARTS
Key Part Number Description
1 F-942 Control Box Lid
2 HH-1487 Igniton Transformer
3 HF-7318 Circuit Board Assembly
4 HH-1092 High Limit Switch 180 Degree
5 FH-4429-1 Spring Latch
6 HH-7015 Snap trak
7 HF-7046 18" Control Box Housing
7 HF-7047 24" Control Box Housing
7 HF-7098 26" Control Box Housing
7 HF-7051 28" Control Box Housing
8 DC-1166 Decal Deluxe Heater Front Panel
9 TFH-2021 Red Light (110V)
10 HH-1442 Toggle Switch
11 HF-7455 High Limit Switch Box Bottom
12 HF-7439 High Limit Switch 250 Degree
13 HF-7454 High Limit Switch Box Top
14 HF-7414 Recessed Plastic Plug
15 TD-100282 Optional Relay
15 FH-1310 Cord Connector
