H3123 Electric Guitar Kit -15-
11. Solder the black wire to the spring hanger.
12. Secure the spring hanger to the guitar body
with the included two 1
1 ⁄
2
" wood screws.
13. Hang the three springs from the spring hang-
er to the tremolo bridge as shown in
Figure
24 .
Figure 24. Correct spring placement.
Strap Button
The strap buttons are positioned on the guitar as
shown in
Figure 25 .
To attach the strap buttons to the guitar body:
1. Using a 3 ⁄
32
" drill bit, drill 3 ⁄
4
" deep holes at
each of the mounting locations .
2. Secure the strap buttons to the guitar body
with the included two
3 ⁄
4
" wood screws.
Figure 25. Strap buttons.
