Page 33
31
ITEM PART
NO. QTY. DESCRIPTION
1
0E8418
1
DUCT INTAKE MID AL
2
0E8414
1
DUCT
DISCHARGE RH AL
3
0E8413
1
DUCT
DISCHARGE LH AL
4
0C2454
62
SCREW TH-FRM M6-1 X 16 N WA Z/JS
5
0E7807
1
BAFFLE REAR BOTTOM
6
0E5902
1
POST CORNER LH REAR HSB AL
7
0E5903
1
POST CORNER RH REAR HSB AL
8
0E8387
1
BAFFLE
REAR
TOP
9
0E5912
2
DOOR
SIDE HSB AL
10
0F5570
1
SUPPORT RH SIDE HSB AL
11
089961
2
FOAM
STRIP 3/4” WIDE X 3/16” THK (40” LG)
12
0A2115
4
WASHER NYLON .257
13
0E8404
1
BRACKET
STIFFENER RH FRONT
14
0D2538A
1
HINGE LIFT OFF TYPE B KNUCKLE
15
0D2538
1
HINGE LIFT OFF TYPE B PIN
16
078115
8
WASHER SELF LOCKING DOME
17
022097
12
WASHER LOCK M6-1/4
18
022473
12
WASHER FLAT 1/4-M6 ZINC
19
0E7570
2
GAS SPRING
20
0E7571
4
BALL
STUD GAS SPRING MOUNT
21
070015
4
NUT HEX 5/16-18 LOCK
22
0E7662
4
SCREW WING M6-1.00 X 25
23
0D2537A
1
HINGE LIFT OFF TYPE A KNUCKLE
24
0D2537
1
HINGE LIFT OFF TYPE A PIN
25
0D2023
2
TRIM
VINYL
SELF GRIPPING (91” LG)
26
0E7869
2
BRACKET
STIFFENING BACK
27
0E8001
1
MUFFLER
BOX
28
0F5568
1
ROOF
HSB AL ACOUSTIC
29
0E8798
1
BRACE,
FRONT
TOP
30
0D3037A
1
LATCH 1/4 TURN NONLOCKING
31
0C7781
2
PAWL DOOR HSB
32
0E5910
1
SUPPORT LH SIDE HSB AL
33
0E8052
1
MUFFLER
BOX
TOP
34
0D3037
1
LATCH QUARTER TURN LOCKING
35
0E5900
1
POST CORNER LH FRONT HSB AL
36
0E5901
1
POST CORNER RH FRONT HSB AL
37
0F4938A
1
BRACE
FRONT
BOTTOM
38
0E8415
1
DUCT
DISCHARGE MID AL
39
026850
4
WASHER SHAKEPROOF EXT 1/4 STL
40
0912970063
2
ASSY WIRE 14AWG 7.5 #0 GRN/YEL
41
0912970064
2
ASSY WIRE 14AWG 7.5 #0 GRN/YEL
42
049813
2
NUT HEX M6 X 1.0 G8 YEL CHR
43
0E8416
1
DUCT INTAKE LH AL
44
0E8417
1
DUCT INTAKE RH AL
45
0E8665
1
BRACKET
STIFFENER LH FRONT
46
0D2023
1
TRIM
VINYL
SELF GRIPPING (165.5” LG)
47
0E7829N
2
AI ROOF PANEL 2
48
0E7829T
1
AI
SUPPORT RH PANEL
49
0E7829S 1
AI
SUPPORT LH PANEL
50 *
0E8442
1
KIT INSULATION 3.9L HSB
51
0E7829A
1
AI ROOF PANEL 1
52
0E7829B
2
AI DOOR PANEL
53
0E7829P
4
AI CORNER POST PANEL 1
54
0E7829R
2
AI CORNER POST PANEL 2
55
043116
8
SCREW HHC M6-1.0 X 12 G8.8
* ALL ITEMS NOTATED WITH “AI” ARE COMPONENTS OF 0E8442
Section 7 - Exploded Views and Parts
40kW Liquid-cooled Generators
Enclosure — Drawing No. 0F4930-C
