Goodman Mfg GDS80904BXCB - Manual (Page 9)

Heat Exchanger Assy
Ref.
No: Part
No:
Description:
Ref.
No: Part
No:
Description:
Image 1:
HEAT EXCHANGER ASSY (M1, M2) 0270F00900 11
HEAT EXCHANGER ASSY (M3, M4) 0270F00901 11
HEAT EXCHANGER ASSY (M5, M6) 0270F00902 11
HEAT EXCHANGER ASSY (M7, M8) 0270F00903 11
FLUE COLLECTOR BOX KIT 14" 1.25 DIA (M1, M2) 0121F00126 21
FLUE COLLECTOR BOX KIT 14" 2.5 DIA (M3, M4) 0121F00208 21
FLUE COLLECTOR BOX KIT 17.5", 2.5 DIA (M5,
M6) 0121F00201 21
FLUE COLLECTOR BOX KIT 21" 2.75 DIA (M7, M8) 0121F00200 21
CHIMNEY TRANSITION BOTTOM 0128F00006 31
VENT MOTOR 0131M00002S 41
GAS VALVE (36G) (M1, M3, M5, M7) B1282628 51
GAS VALVE (HONEYWELL 1 STG) (M2, M4, M6,
M8) 0151M00013 51
MANIFOLD (M1, M2) 0120F00006 61
MANIFOLD (M3, M4) 0120F00007 61
MANIFOLD (M5, M6) 0120F00008 61
MANIFOLD (M7, M8) 0120F00009 61
ORIFICE (QTY AR) 10716003 71
INSHOT BURNER ASSY 3" (QTY AR) B4022700 81
BURNER BRACKET 2B (M1, M2) 0121F00167 91
BURNER BRACKET 3B (M3, M4) 0121F00168 91
BURNER BRACKET 4B (M5, M6) 0121F00169 91
BURNER BRACKET 5B (M7, M8) 0121F00170 91
BURNER BOX TOP 2 CELL (M1, M2) 0121F00162 101
BURNER BOX TOP 3 CELL (M3, M4) 0121F00163 101
BURNER BOX TOP 4 CELL (M5, M6) 0121F00164 101
BURNER BOX TOP 5 CELL (M7, M8) 0121F00165 101
MANUAL RESET LIMIT 10123529 111
BURNER BOX SIDE (QTY 2) 0121F00146 121
FLAME SENSOR 0130F00010 131
IGNITOR 20165703S 141
PRIMARY LIMIT - PINK (M5, M6, M7, M8) 0130F00036 151
PRIMARY LIMIT - PURPLE 220º (M1, M2, M3, M4) 0130F00035 151
ORIFICE SHIELD 2 CELL (M1, M2) 4028000 161
ORIFICE SHIELD 3 CELL (M3, M4) 4028001 161
ORIFICE SHIELD 4 CELL (M5, M6) 4028002 161
ORIFICE SHIELD 5 CELL (M7, M8) 4028003 161
VENT MOTOR GASKET 14" (M1, M2, M3, M4) 0154F00003 171
VENT MOTOR GASKET 17.5" (M5, M6) 0154F00004 171
VENT MOTOR GASKET 21" (M7, M8) 0154F00005 171
Expanded Model Nomenclature
M1 - GDS80453AXCA
M2 - GDS80453AXCB
M3 - GDS80703AXCA
M4 - GDS80703AXCB
M5 - GDS80904BXCA
M6 - GDS80904BXCB
M7 - GDS81155CXCA
M8 - GDS81155CXCB
9 RP-564A www.goodmanmfg.com
