Jumpers
Jumper Name Description Page
JP1 Keyboard Power ON Function Setting 3-pin Block p.5
JP3 USB Power On Function Setting 3-pin Block p.5
JBAT CMOS RAM Clear Function Setting 3-pin Block p.6
Connectors
Connector Name Description Page
ATXPWR ATX Power Connector 20-pin Block p.10
KB/MS1 PS/2 Mouse & PS/2 Keyboard Connector 6-pin Female p.10
UL1 / UL2 RJ45 Over USB Connector 4-pin Connector p.11
COM1 Serial Port Connector 25-pin Female p.11
VGA VGA Port Connector 15-pin Female p.11
Line-In/Out, MIC Line-Out/Line-In/MIC Audio Connector Phone Jack p.11
IDE1 Primary/Secondary Connector 40-pin Block p.11
SATA1/2 Serial ATA IDE Connector 7-pin Connector p.12
Headers
Header Name Description Page
COM2 COM2 Serial Port Headers 10-pin Block p.12
PARALLEL Parallel Port Headers 25-pin Block p.12
AUDIO Line-Out/MIC output Header 4-pin Block p.13
USB1/USB2 USB2.0 Port Headers 10-pin Block p.13
HD_LED Hard drive LED connector 3-pin Block p.13
RESET Reset switch lead 2-pin Block p.13
SPEAK Speaker connector 4-pin Block p.13
PWR LED Power LED Headers 2-pin Block p.13
PWR BTN Power Button Headers 2-pin Block p.14
CPUFAN, SFAN1/2 FAN Speed Headers 3-pin Block p.14
CDIN CD Audio-In Headers 4-pin Block p.14
Expansion Sockets
Socket/Slot Name Description Page
DDR2 DDR2 SDRAM Module
Socket 240-pin DDR2 SDRAM Module
Expansion Socket p.8
PCI1 PCI Slot 32-bit PCI Local Bus Expansion slots p.9
