2
1-2 Specification
Spec Description
Design
∗ Mini ITX form factor 6 layers PCB size: 17.0x17.0cm
Chipset
∗ VIA CN700 Chipset
∗ VIA VT8237R Plus Chipset
CPU
∗ Embedded VIA CN700 NANO BGA processor
Memory Socket
∗ 240-pin DDR2 DIMM socket x1
∗ Support DDR2 533/400 system RAM Modules DDR memory
∗ Expandable to 1GB
Expansion Slot
∗
32-bit PCI slot x 1cs
Integrate VGA
∗ Integrate 2D/3D graphic Engines
∗ 8/16/32/64MB frame buffer using system memory
∗ Internal AGP 8x performance
∗ Support 24-bit 250MHz RAMDAC
Integrate IDE and
Serial ATA RAID
∗ Two PCI IDE controllers support PCI Bus Mastering, ATA
PIO/DMA and the ULTRA DMA 33/66/100/133 functions that
deliver the data transfer rate up to 133 MB/s; Two Serial ATA
ports provide 150 MB/sec data transfer rate for two Serial ATA
Devices and offer RAID 0, 1, JBOD functions
Dual 10 / 100 LAN
(For 7F4B Series)
∗ Integrated Dual Realtek RTL8100C LAN Chip supporting 10/100
BASE-T Transfer rate
Dual Gigabit LAN
(For 7F4K Series)
∗ Integrated Dual Realtek RTL8110SC LAN Chip supporting
10/100/1000 BASE-T Transfer rate
Audio
∗ AC’97 Digital Audio controller integrated
∗ 6-channel AC’97 Audio CODEC onboard
∗ Audio driver and utility included
BIOS
∗ Award 4Mb Flash ROM
Multi I/O
∗ PS/2 keyboard and PS/2 mouse connectors
∗ Hard disk drive connector x1
∗ VGA x1, Serial port x1
∗ USB 2.0 connector x2
∗ USB 2.0 Pin-header x2 (connecting cable is option)
∗ Parallel Port Pin-header x1(connecting cable is option)
∗ Serial COM Port COM2 Pin-header x1(connecting cable is option)
∗ Audio connector (Line-in, Line-out, MIC)
