GA-8IDML Series Motherboard
48
Frequency/Voltage Control
CPU Clock Ratio
X 8~X 24 It’s depends on CPU Clock Ratio.
CPU Host Cl ock Control
Disable Disable CPU H ost Clock Control.(Default value)
Enable Enable CPU H ost Clock Control.
CPU Host Frequency
100MHz ~ 200MHz Set CPU Host Clock from 100MHz to 200MHz.
Host/DRAM Clock Ratio
1.0 Memory Frequency = Host clock X 1.0.
1.33 Memory Frequency = Host clock X 1.33.
Auto Depend’s On SPD Data. (Default value)
Figure 9: Frequency/Voltage Control
CMOS Setup Utility-Copyright (C) 1984-2001 Award Software
Frequency/Voltage Control
CPU Clock Ratio x 15 Item Help
CPU Host Clock Control Disable Menu Level
CPU Host Frequency(MHz) 100
Host/DRAM Clock ratio Auto
Memory Frequency(MHz) 133
PCI/AGP Frequency(MHz) 33/66
????: Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
