GA-8IDML Series Motherboard
30
Advanced Chipset Features
Configure DRAM Timing
SPD
Set Configure DRAM Timing Control by SPD. (Default value)
Manual
Set SConfigure DRAM Timing Control by Manual.
CAS latency Time
3
For Slower SDRAM DIMM module.
2
For Fastest SDRAM DIMM module.
(Default Value)
Active to Precharge Delay
5
Set active to Precharge delay timing is 5 clk. (Default value)
6
Set active to Precharge delay timing is 6 clk.
7
Set active to Precharge delay timing is 7 clk.
Figure 4: Advanced Chipset Features
CMOS Setup Utility-Copyright (C) 1984-2001 Award Software
Advanced Chipset Features
Configure DRAM Timing
SPD
Item Help
?CAS Latency Time
2
Menu Level
?Active to Precharge Delay
5
?DRAM RAS# to CAS# Delay
2
?DRAM RAS# Precharge
2
?Refresh Mode Select
15.6usec
DRAM Data Integrity Mode
Non-ECC
DRAM Read Thermal Mgmt
Disable
Delay Transaction
Enable
AGP Aperture Size(MB)
64
Delay Prior to Thermal
16Min
????: Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
