Page 33
Generac
®
Power Systems, Inc.
31
ITEM
PART NO.
QTY.
DESCRIPTION
1
0C3250
1
ASSEMBLY BASE MOUNTING (DIRECT-COUPLED)
3
055414
1
LUG SLDLSS #2-#8 X 17/64 CU
4
0A4084
2
MOUNT ENGINE (R&L)
5
022129
2
WASHER LOCK M8-5/16
6
045771
2
NUT HEX M8-1.25 G8 YEL CHR
7
022237
6
WASHER LOCK 3/8
8
029745
6
SCREW HHC 3/8-16 X 1 G5
10
043107
2
SCREW HHC M8-1.25 X 25 G8.8
11
022145
2
WASHER FLAT 5/16 ZINC
12
027482
3
WASHER SHAKEPROOF EXT 5/16 STL
13
055597
4
SCREW HHC M12-1.75 X 85 G8.8
14
052251
2
DAMPENER VIBRATION 40 BLUE
15
052257
4
SPACER .49 X .62 X 1.87 PWDR/ZINC
16
052252
4
DAMPENER VIBRATION
17
052259
4
WASHER FLAT M12
18
052860
4
NUT LOCKING M12-1.75
19
0536210098
1
ASSEMBLY GROUNDWIRE 10"/3/8
20
052251A
2
DAMPENER VIBRATION 50 WHITE
21
044118
1
BARBED STRAIGHT 1/2 NPT X 5/8
22
057823
2
CLAMP HOSE #10 .56 - 1.06
23
057448
11"
HOSE 5/8 ID TYPE 3 SINGLE
24
024310
1
PLUG STD PIPE 1/2 STEEL SQ HD
* 25
0A8785
4
PLUG BUTTON 3" DIA.
* 26
0C4360
8
PLATE VARMINT
* 27
071693
16
WASHER FLAT .281 ID X 1.0 OD
* 28
0C2454
16
SCREW TH-FRM M6-1 X 16 N WA Z/JS
* 29
0C4753
1
PLUG 3/4 BUTTON
30
022413
1
SCREW HHC 1/4-20 X 1 G5
31
022473
1
WASHER FLAT 1/4 ZINC
32
022097
1
WASHER LOCK M6-1/4
33
022127
1
NUT HEX 1/4-20 STEEL
NOTES: 1) * ITEMS 25, 26, 27, 28 & 29 ARE INCLUDED FOR UNITS WITH ENCLOSURES ONLY. NOT INCLUDED WITH OPEN SETS.
2) ITEM 25 (PLUG BUTTON 3" DIA.) IS USED AFTER SHIPPING. HOLES ARE TO REMAIN UNCOVERED FOR SHIPPING PURPOSES. PLUGS CAN
BE FOUND IN THE MANUAL BAG LOCATED INSIDE THE LOWER CONNECTION BOX.
Section 7 — Exploded Views and Parts Lists
(Model Nos. 004373-3 & 004626-2) Guardian Liquid-cooled 40 kW Generators
Base - Drawing No. 0C4399-D
