Exploded View Model 5511 Base Assembly
5511-0107-021-5-15-00
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
18
20
21
23
24
27
28
29
30
31
32
33
W0210169
W0200133
W0200256
W0200411
W0200412
W0200413
W0201079
W0210041
W0320020
W0320220
W0320286
W0321013
W0671017
W0380009
W0450016
W0321025
W0611074
W0611082
W0611246
W0610657
W0671018
W0671021
W0671022
W0340111
W0630421
W0610559
W0611248
Motor Cradle
Compressor
Condenser
Fan Mount Bracket
Compressor Spacer
Compressor Grommet
Fan Shroud
Frame Bottom Plate
Drive Motor
Fan Motor
Fan Blade
Motor Adj. Nut
Sound Insulation (Fan)
Flange Bearing
Pulley
Motor Stop Bracket
1/4-20 Hex Nut
5/16-18 Flange Nut
1/4 Lock Washer
5/16-18 x 1/2 Cap
Sound Insulation (Cond)
Sound Insulation (Shro)
Sound Insulation (Motor)
Isolation Bumper
Nylon Cable Clamp
Screw, 1/4-20 x 1 socket Hd. Cap
Lock Washer, 1/4” Split z/p
Item Part Number Description
