Page 20 Crathco
®
5000 Series Manual
5000 SERIES FREEZER SPECIFICATIONS:
Specification Model 5311 Model 5511 Model 5711 Model 5941
Circuit NEMA# NEMA 5-20R NEMA 6-20R NEMA 6-20R NEMA 5-15R
Electrical
115 volt, 60 Hz, 1 Phase
Dedicated 20 Amp circuit
208/230 volt, 60 Hz, 1
Phase
Dedicated 20 Amp circuit
208/230 volt, 60 Hz,
1 Phase 115 volt, 60 Hz, 1 Phase
15 Amp circuit
Drive Motor 1/4 hp, Capacitor Start/Run 1/2 hp, Capacitor Start/Run 1/2 hp, Capacitor Start/Run 1/4 hp, Capacitor Start/Run
Compressor 3/4 hp 1 hp 1-1/2 hp
N/A
Note: Freezer must be
connected to a separate
condensing unit.
Cooling
Air Cooled
(Optional Water Cooled)
Air Cooled Air Cooled N/A
Actual Weight 175 lbs. (79.4 kg) 185 lbs. (84 kg) 260 lbs. (97 kg) 140 lbs. (63.5 kg)
Mix Hopper Capacity 5 gallons (18.9 liters) 5 gallons (18.9 liters) 5 gallons (18.9 liters) 5 gallons (18.9 liters)
Freezing Cylinder
Capacity
1-1/2 gallons (5.7 liters) 1-1/2 gallons (5.7 liters) 1-1/2 gallons (5.7 liters) 1-1/2 gallons (5.7 liters)
Refrigerant See Serial Number Plate See Serial Number Plate See Serial Number Plate See Serial Number Plate
Refrigerant Charge See Serial Number Plate See Serial Number Plate See Serial Number Plate See Serial Number Plate
High Side
(approximate operating
pressure)
275 to 350 psi
(19 to 25 k/cm) 275 to 350 psi
(19 to 25 k/cm) 275 to 350 psi
(19 to 25 k/cm) 240 to 270 psig
(ambient dependent)
Low Side
(approximate operating
pressure) 35 (w/ standard) to
45 (w/ scraper blade auger)
psi (2.5 to 3 k/cm)
40 psig
(w/ scraper blade auger)
32 to 40 psig
32 to 38 psig
(load dependent)
High Side Design
Pressure
420 psig 460 psig 331 psig 420 psig
Low Side Design
Pressure
174 psig 174 psig 174 psig 174 psig
Specifications are subject to improvement or change without notice.
