Page 43
41
ITEM PART
NO.
QTY.
DESCRIPTION
1
0D5694 1
CASTING, TWIN REGULATOR HOUSING
2
0F4795 4
SCREW PPHM SEMS M4-0.7 X 10
5
0F5022
1
SOLENOID COIL, 12VDC
6
0C6070
1
SPRING-SOLENOID PLUNGER
7
0C4680
1
PLUNGER LP REG. ASSY
8 0C4647
1
GASKET, SOLENOID
9 0C4643
1
INLET, TWIN REGULATOR NO HOLE
10
0D3973 1
PLUG,
EXPANSION 16MM TWINREG
11
0E6183 1
ELBOW
90D STREET 1/2" BRASS
12
072683A 2
PLUG
1/8" NPTF PIPE
13 0D3308 2
WASHER FLAT 3.2MM ID X 10MM OD
14
070728 2
SCREW PFILHM M3-0.5 X 5
15
0C5764A
1
SPRING, REGULATOR 45N/M 29MM
16
0C4643A
1
INLET, TWIN REG 11.11 DIA.
17
0C6066
1
SEAL, INLET REGULATOR
18 0C5968 1
SUPPORT, INLET SEAL
19 0C5759
1
PIN, PIVOT ARM
20
0C5761
1
LEVER,
REGULATOR
21
0C6069 1
GASKET, DIAPHRAGM
22
0C6731 1
RIVET
.118 X .125 ALUMINUM
23 0C6067
1
SUPPORT, DIAPHRAGM
24
0C4706
1
DIAPHRAGM,
TWIN
REGULATOR
25
0C6068 1
CAP,
DIAPHRAGM
SUPPORT
26
0C5762
1
COVER,TWIN
REGULATOR
27
045764
8
SCREW HHTT M4-0.7 X 8 BP
28 0C6606
1
BARBED
STR 1/2" X 1/2" NPT
29 0E4170
1
CONNECTION
3/4"NPT - 3/8" 45D
30
0C5760
1
JET LP GN220 ENGINE
Section 6 — Exploded Views and Parts Lists
Recreational Vehicle Generator
Regulator (Model 02010-2) – Drawing No. 0F1125-C
