14 MDS Mercury Series Startup Guide 05-4558A01, Rev. C
SPECIFICATIONS
GENERAL
Temperature Range: –40° C to +70° C (–40° F to 158° F)
Humidity: 95% at +40° C (104° F); non-condensing
Primary Power: 10–30 Vdc
External Power Supply Options: 48 Vdc; 110–120/210–220 Vac
Typical Current Consumption (assumes 1 Watt RF Output):
Size (without mtg. hardware): 5.72 H x 20 W x 12.38 D cm
(2.25 H x 7.88 W x 4.88 D in.)
Mounting Options: Flat surface brackets, DIN rail, 19” rack
Weight: 1kg / 2.2 lb.
Case: Die Cast Aluminum
RADIO CHARACTERISTICS
GENERAL:
Frequency Band:
Mercury 900: 902–928 MHz
Industrial, Scientific & Medical (ISM) Band
Mercury 3650: 3650–3700 MHz
FCC Registered Band
TRANSMITTER:
RF Output @ connector:
Mercury 900: –30 to +30 dBm
Mercury 3650: 0 to 20 dBm
Increments of 1.0 dB, set
by user
Duty Cycle: Continuous
Output Impedance: 50 Ohms
RECEIVER:
Type:
Double conversion superheterodyne
Sensitivity and Data Rate: Dependent on modulation and bandwidth.
See
Reference Manual Specifications.
Mode DC Power 13.8 Vdc 24 Vdc
AP Transmit 25 W 1.8 A 1.0 A
AP Receive 8 W 579 mA 333 mA
RM Transmit 25W 1.8 A 1.0 A
RM Receive 6.5W 471 mA 270 mA
