7
Note: The air performance data shown does not include internal static pressure losses due to items such as filters, dampers, and coils. For
exact air performance data based on specific unit configuration, use the Greenheck CAPS selection program.
Blower
Size
CFM
TOTAL PRESSURE in inches WG
0.75 1.00 1.25 1.50 1.75 2.00
Housing 12
108
800
RPM 1109 1216 1311 1399 - -
BHP 0.26 0.31 0.35 0.40 - -
1,200
RPM 1347 1445 1530 - - -
BHP 0.59 0.68 0.75 - - -
109
1,500
RPM 1014 1140 1255 1361 1460 -
BHP 0.45 0.54 0.63 0.73 0.84 -
2,400
RPM 1216 1306 1397 1484 1569 1648
BHP 1.1 1.3 1.4 1.6 1.7 1.9
110
2,000
RPM 912 1013 1110 1199 - -
BHP 0.59 0.71 0.08 0.10 - -
3,000
RPM 1097 1172 1244 1315 1386 1455
BHP 1.4 1.6 1.7 1.9 2.1 2.2
Housing 22
112
2,600
RPM 761 853 934 1009 - -
BHP 0.7 0.9 1.0 1.2 - -
4,400
RPM 939 1006 1073 1137 1197 1254
BHP 2.1 2.4 2.6 2.9 3.1 3.3
115
4,000
RPM 681 756 822 892 - -
BHP 1.3 1.5 1.8 2.1 - -
6,500
RPM 850 906 960 1013 1062 1110
BHP 3.5 3.9 4.3 4.7 5.1 5.5
Housing 32
118
6,500
RPM 609 668 724 777 - -
BHP 2.1 2.5 2.8 3.2 - -
9,500
RPM 736 783 827 872 914 954
BHP 4.9 5.4 5.9 6.4 6.9 7.4
120
10,000
RPM 590 634 678 723 765 803
BHP 4.0 4.5 5.0 5.6 6.1 6.6
15,000
RPM 763 795 829 861 892 921
BHP 10.9 11.6 12.3 13.1 13.8 14.5
Housing 35
122
15,000
RPM 605 637 667 698 727 755
BHP 8.3 8.9 9.6 10.4 11.1 11.9
19,000
RPM 720 746 771 796 821 845
BHP 15.2 16.1 17.0 17.8 18.6 19.4
125
19,000
RPM 563 594 625 655 683 711
BHP 9.8 10.7 11.7 12.8 13.8 14.8
23,000
RPM 643 671 967 723 748 -
BHP 15.9 16.9 18.0 19.2 20.4 -
Housing 38
127
24,000
RPM 451 478 504 530 554 578
BHP 11.6 13.0 14.3 15.8 17.2 18.6
30,000
RPM 525 548 571 593 613 -
BHP 19.6 21.4 23.2 24.9 26.6 -
130
26,000
RPM - 412 440 467 494 520
BHP - 12.5 13.9 15.2 16.8 18.3
34,000
RPM 454 477 499 519 542 -
BHP 21.5 23.1 24.8 26.4 28.3 -
Housing 42
133
32,000
RPM 371 397 422 446 467 488
BHP 15.7 17.5 19.2 21.0 22.6 24.3
40,000
RPM 426 448 470 491 512 531
BHP 27.1 29.1 31.5 33.7 35.8 37.9
136
42,000
RPM 405 426 445 464 482 499
BHP 27.7 29.8 32.0 34.1 36.3 38.5
48,000
RPM 447 465 483 500 - -
BHP 39.0 41.5 44.0 46.4 - -
AIR PERFORMANCE
