Chassis
Ref.
No: Part
No:
Description:
Ref.
No: Part
No:
Description:
Image 1:
BASE PAN (M1, M2, M5, M7, M8, M13) 20273510 11
BASE PAN (M3, M4, M6, M9, M10, M11, M12, M14) 20273512 11
BLOWER DECK (M1, M2, M5, M7, M8, M13) 0121F00046 31
BLOWER DECK (M3, M4, M6, M9, M10, M11, M12,
M14) 0121F00049 31
BACK PANEL (M1, M2, M5, M7, M8, M13) 20273216 81
BACK PANEL (M3, M4, M6, M9, M10, M11, M12,
M14) 20273218 81
HEAT EXCHANGER INSULATION (M3, M4, M6,
M9, M10, M11, M12, M14) C6415909 91
HEAT EXCHANGER INSULATION (M1, M2, M5,
M7, M8, M13) C6415911 91
DECK RAIL (M1, M2, M5, M7, M8, M13) 0121F00019P 101
DECK RAIL (M3, M4, M6, M9, M10, M11, M12, M14) 20191303 101
TOP COVER ASSY (M1, M2, M5, M7, M8, M13) 0270F00104PS 111
TOP COVER ASSY (M3, M4, M6, M9, M10, M11,
M12, M14) 0270F00105P 111
SIDE RAIL (M1, M2, M5, M7, M8, M13) 20191603 121
SIDE RAIL (M3, M4, M6, M9, M10, M11, M12, M14) 20191604 121
SIDE PANEL LH 0121F00093DG 141
SIDE PANEL RH 0121F00091DG 151
INSULATION (M1, M2, M5, M7, M8, M13) 20006602 161
INSULATION (M3, M4, M6, M9, M10, M11, M12,
M14) 20006603 161
SIDE INSULATION (QTY 2) 20006604 171
INTERLOCK SWITCH B1370818 221
ELBOW 20171802S 241
ID BLOWER 20245903S 271
FA COUPLING (QTY 2) 20049701 281
PRESSURE SWITCH (M5, M6, M13, M14) 0130F00070 291
PRESSURE SWITCH-PINK (M1, M2, M3, M4, M7,
M8, M9, M10, M11, M12) 20197313 291
PRESSURE SWITCH (M5, M6, M13, M14) 0130F00100 301
PRESURE SWITCH-LIME (M1, M2, M3, M4, M7,
M8, M9, M10, M11, M12) 11177118 301
PLASTIC SEALER M0275521 391
JUNCTION BOX 0161F00004S 411
JUNCTION BOX COVER 0161F00005S 431
ID BLOWER SHIELD 11165107 591
HOSE CLAMP (QTY 2) 0163M00049 611
TUBE PLUG M0326804 701
GASKET (QTY 2) 20194608 791
GASKET (M1, M2, M5, M7, M8, M13) 20194606 811
GASKET (M3, M4, M6, M9, M10, M11, M12, M14) 20194607 811
ELBOW - 22 1/2 ELL C6455901 891
PRESSURE SWITCH HOSE 0164M00003 NS
PRESSURE SWITCH HOSE (M1, M2, M5, M7, M8,
M13) 0164M00011 NS
Image 1:
PRESSURE SWITCH HOSE (M3, M4, M6, M9, M10,
M11, M12, M14) 0164M00013 NS
Expanded Model Nomenclature
M1 - ACVC90704CXAA
M2 - ACVC90704CXAB
M3 - ACVC90905DXAA
M4 - ACVC90905DXAB
M5 - ACVC950714CXAA
M6 - ACVC950915DXAA
M7 - GCVC90704CXAA
M8 - GCVC90704CXAB
M9 - GCVC90905DXAA
M10 - GCVC90905DXAB
M11 - GCVC91155DXAA
M12 - GCVC91155DXAB
M13 - GCVC950714CXAA
M14 - GCVC950915DXAA
9 RP-508C www.goodmanmfg.com www.amana-hac.com
