2-3 Integrated Peripherals
CMOS Setup Utility-Copyright (C) 1984-2004 Award Software
Integrated Peripherals
On-Chip Primary PCI IDE [Enabled]
SATA RAID/AHCI Mode [RAID]
x On-Chip SATA Mode Auto
x PATA IDE Set to Ch.1 Master/Slave
SATA Port 0/2 Set to Ch.2 Master/Slave
SATA Port 1/3 Set to Ch.3 Master/Slave
USB Controller [Enabled]
USB 2.0 Controller [Enabled]
USB Keyboard Support [Disabled]
USB Mouse Support [Disabled]
Azalia Codec [Auto]
Front Panel Type [HD Audio]
Onboard H/W 1394 [Enabled]
Onboard H/W SATA [Enabled]
H/W SATA Function [RAID]
Onboard H/W LAN1 [Enabled]
Onboard H/W LAN2 [Enabled]
Onboard LAN1 Boot ROM [Disabled]
Onboard LAN2 Boot ROM [Disabled]
KLJI: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F3: Language F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level`
CMOS Setup Utility-Copyright (C) 1984-2004 Award Software
Integrated Peripherals
KLJI: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F3: Language F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level`
On-Chip Primary PCI IDE
Enabled Enable onboard 1st channel IDE port. (Default value)
Disabled Disable onboard 1st channel IDE port.
SATA RAID / AHCI Mode
RAID Select onboard Serial ATA function as RAID. (Default value)
AHCI Support hotplug function under OS. WinXP, 2000 only.
Disabled Select onboard Serial ATA function as ATA.
On-Chip SATA Mode
Disabled Disable this function.
Auto BIOS will detect automatically. (Default value)
Combined Set On-Chip SATA mode to Combined, you can use up to 4 HDDs on the motherboard;
2 for SATA and the other for PATA IDE.
Onboard Serial Port 1 [3F8/IRQ4]
Onboard IrDA Port [2F8/IRQ3]
UART Mode Select [IrDA]
UR2 Duplex Mode [Half]
Onboard Parallel Port [378/IRQ7]
Parallel Port Mode [SPP]
x ECP Mode Use DMA 3
