Page 20 Crathco
®
5000 Series Manual
5311 FREEZER SPECIFICATIONS:
5511 FREEZER SPECIFICATIONS:
Circuit NEMA# NEMA 5-20R
Electrical
115 volt, 60 Hz, 1 Phase
Dedicated 20 Amp circuit
Drive Motor 1/4 hp, Capacitor Start/Run
Compressor 3/4 hp
Cooling Air Cooled (Optional Water Cooled)
Actual Weight 175 lbs. (79.4 kg)
Mix Hopper Capacity 5 gallons (18.9 liters)
Freezing Cylinder Capacity 1-1/2 gallons (5.7 liters)
Refrigerant See Serial Number Plate
Refrigerant Charge See Serial Number Plate
High Side (approximate operating pressure) 275 to 350 psi (19 to 25 k/cm)
Low Side (approximate operating pressure) 35 (w/ standard) to 45 (w/ scraper blade auger) psi (2.5 to 3 k/cm)
High Side Design Pressure 420 psig
Low Side Design Pressure 174 psig
Circuit NEMA# NEMA 6-20R
Electrical
208 volt, 60 Hz, 1 Phase
Dedicated 20 Amp circuit
Drive Motor 1/2 hp, Capacitor Start/Run
Compressor 1 hp
Cooling Air Cooled
Actual Weight 185 lbs. (84 kg)
Mix Hopper Capacity 5 gallons (18.9 liters)
Freezing Cylinder Capacity 1-1/2 gallons (5.7 liters)
Refrigerant See Serial Number Plate
Refrigerant Charge See Serial Number Plate
High Side (approximate operating pressure) 275 to 350 psi (19 to 25 k/cm)
Low Side (approximate operating pressure) 40 psig (w/ scraper blade auger)
High Side Design Pressure 460 psig
Low Side Design Pressure 174 psig
5941 FREEZER SPECIFICATIONS:
Circuit NEMA# NEMA 5-15R
Electrical
115 volt, 60 Hz, 1 Phase
15 Amp circuit
Drive Motor 1/4 hp, Capacitor Start/Run
Compressor
N/A; Note: Freezer must not be connected to a condensing unit
less than 2 hp.
Actual Weight 140 lbs. (63.5 kg)
Mix Hopper Capacity 5 gallons (18.9 liters)
Freezing Cylinder Capacity 1-1/2 gallons (5.7 liters)
Refrigerant See Serial Number Plate
Refrigerant Charge See Serial Number Plate
High Side (approximate operating pressure) 240 to 270 psig (ambient dependent)
Low Side (approximate operating pressure) 38 to 32 psig (load dependent)
High Side Design Pressure 420 psig
Low Side Design Pressure 174 psig
