HOW TO PROPERLY USE THE URBAN ADVANTAGE 10
6. TO ADJUST THE KICKSTAND
!
WARNING: IF THE CABLE IS NOT ADJUSTED PROPERLY OR
THE KICKSTAND IS BENT OR BROKEN THE STABILITY OF THE
STROLLER IN THE PARKED POSITION IS DIMINISHED. IN ALL
EVENTS, NO CHILD SHOULD EVER BE LEFT UNATTENDED IN ANY
STROLLER.
Turning the nut connected to the brake cable clockwise reduces the
amount of force required to extend the kickstand. Turning the nut
counter-clockwise increases the tension on the cable and adjusts the
forward lean of the legs. (fi gure A)
The legs of the kickstand must be vertical when the unit is parked in
order to be effective. Adjust the nut to keep legs in vertical position
with the least amount of force required. The cable will require re-
adjusting over time as parts wear.
There should approximately 1/2" to 1" clearance between the bottom
of the kickstand and the ground. This allows for lower air pressure in
tires and/or heavier children.
6. OPTIONS FOR USING THE CHILD TRAY
NOTE: Some parents may prefer not to install the child tray on the
stroller as this option may allow easier accessibility to the child.
(fi gure B & C)
Ex: Diaper changing or feeding. The child tray may be easily
attached and removed by pulling off or snapping on each side to
the frame of the stroller (just below the center lock on the frame and
above the foot rest)
7. OPTIONS FOR USING THE SWIVEL WHEEL LOCK
TO LOCK FRONT SWIVEL: Adjust front wheel so that wheel is
straight and lock is forward. Push lock to right. (fi gure D)
TO UNLOCK FRONT SWIVEL: Push lock to left.
NOTE: On rough surfaces, lock the wheel to keep straight. On
smooth surfaces, unlock to allow the wheel to swivel.
How to Properly
Use the Urban
Advantage Stroller
Figure A
Figure C
Figure D
Figure B
