U.S. RANGE PARTS IDENTIFICATION
Summit Series Gas Convection Ovens
models SUMG-100/200
DOOR COMPONENTS & ASSEMBLIES
( for units manufactured UP TO 14-APRIL-2005)
ITEM
PART #
DESCRIPTION
QTY
FROM
DATE
UP TO
DATE
CRITIC
AL
24
1924712
Seal - Door, Bottom
1
25
1924601
Seal - Door, Left & Right
2
26
1924711
Seal - Door Top
1
27
1924402
Seal - Door, Center (old style)
Note: Use 1924411 (item 28).
1
28
1924411
Center Right Seal
From serial # 0301CJ0082
1
JAN-03
29
1924412
Center Left Seal
From serial # 0301CJ0082
1
JAN-03
30
1928209
Plate Door Handle
From serial # 0301CJ0082
Note: Item will not be available once stock is out.
1
JAN-03
31
1925013
Bracket - Door Stop L/H
1
APR-00
4519740
Bracket - Door Stop R/H
1
APR-05
32*
8003603
Carriage Bolt 3/8-16 X 3/4
34*
1019800
Self Threading Pal Nut
35*
8001210
Nut Hex 3/8-16 Stl 2P
3
36*
8000308
Washer - Flat 3/8x3/4 Stl 2P
3
37*
1915914
Insulation - Left Door, W/Window
1
1915915
Insulation - Left Door, Solid
1
38*
1915916
Insulation Right Door, W/Window
1
1915917
Insulation - Right Door, Solid
1
LEFT DOOR - COMPLETE ASSEMBLIES
(includes Left Door Components and the Left Door Center Seal)
60
CK1924869
Door Kit - Left (WINDOW)
Note: Item will not be available once stock is out.
CK1924868
Door Kit - Left (SOLID)
Note: No Longer Available. ALT CK1924869.
RIGHT DOOR - COMPLETE ASSEMBLIES
(includes Right Door Components and the Right Door Center Seal)
61
CK1924965
USR Door Kit - Right (WINDOW)
Note: Used FROM 01-Jan/2003 UP TO 14-Apr/2005.
CK1924964
USR Door Kit - Right (SOLID)
Note: Used FROM 01-Jan/2003 UP TO 14-Apr/2005.
* NOT ILLUSTRATED
