G250/G250HR, G3000/G3000HR and S3000 Gear Flow Meters
HG6000/HG6000HR and Coriolis Mass Flow Meters
©2010 Graco Inc. Form No. 336165 Rev. D 2/10 Printed in the U.S.A.
All other brand names or marks are used for identification purposes and are trademarks of their respective owners.
* ProMix 2KS Meter Kit Part Number 15V806
** ProMix 2KS Meter Kit Part Number 258151
G250
G250HR
G3000
G3000HR
S3000
Part number
249426
249427
239716
289813 (90º Sensor)
244292,
289814 (90º Sensor)
258718
Maximum working fluid
pressure
250 psi
(17 bar, 1.7 MPa)
250 psi
(17 bar, 1.7 MPa)
4000 psi
(276 bar, 28 MPa)
4000 psi
(276 bar, 28 MPa)
3000 psi
(207 bar, 20 MPa)
Flow range
75 - 3,800 cc/min
38 - 1,900 cc/min
75 - 3,800 cc/min
38 - 1,900 cc/min
50 - 2,000 cc/min
Viscosity range
20 - 3,000 cps
20 - 3,000 cps
20 - 3,000 cps
20 - 3,000 cps
0.5 - 1,000 cps
Resolution
0.119 cc/pulse
0.061 cc/pulse
0.119 cc/pulse
0.061 cc/pulse
0.021 cc/pulse
Material compatibility
Solventborne paints and
resins (low solids), oil and
catalysts
Solventborne paints and
resins (low solids), oil and
catalysts
Solventborne paints and
resins (low solids), oil and
catalysts
Solventborne paints and
resins (low solids), oil and
catalysts
Solvents, solventborne paints
(no filled materials), oil and
catalysts
Wetted parts
303 SST, tungsten carbide
and PTFE
303 SST, tungsten carbide
and PTFE
303 SST, tungsten carbide
and PTFE
303 SST, tungsten carbide
and PTFE
303 SST and PTFE
Recommended uses
Most commonly used
flow meter in finishing
applications. Uses include
solventborne polyurethanes
and epoxies
Low flow version of G3000.
Flow rates as low as
50 cc/min
Most commonly used
flow meter in finishing
applications. Uses include
solventborne polyurethanes
and epoxies
Low flow version of G3000.
Flow rates as low as
50 cc/min
Solvent tracking and metering
of low viscosity materials
Instruction manuals
308778
308778
308778
308778
308778
HG6000
HG6000HR
Coriolis Mass Flow
Coriolis Mass Flow
Part number
280560
246652
15T633* (1/8” ID)
15T634** (3/8” ID)
Maximum working fluid
pressure
6000 psi
(410 bar, 41 MPa)
6000 psi
(410 bar, 41 MPa)
2300 psi
(158 bar, 16 MPa)
2300 psi
(158 bar, 16 MPa)
Flow range
50 - 22,700 cc/min
25 - 7,571cc/min
20 - 4,000 cc/min
20 - 8,000 cc/min
Viscosity range
30 - 1,000,000 cps
30 - 1,000,000 cps
0.1 - 3,000 cps
0.1 - 3,000 cps
Resolution
0.286 cc/pulse
0.143 cc/pulse
0.061 cc/pulse, adjustable
0.061 cc/pulse, adjustable
Material compatibility
Solventborne and waterborne paints
and resins, oil and catalysts
Solventborne paints and resins, oil
and catalysts
Solventborne and waterborne
materials, catalyzed varnishes
and oil
Solventborne and waterborne
materials, catalyzed varnishes
and oil
Wetted parts
303 SST, tungsten carbide, and
PTFE
303 SST, tungsten carbide, and
PTFE
303 and 440 SST and PTFE
303 and 440 SST and PTFE
Recommended uses
Use with viscosities up to 100,000
cps and when flow rates exceed
4000 cc/min
Low flow version of G3000. Flow
rates as low as 50 cc/min
Use with virtually any material and
flow rate. Non intrusive design.
Common uses include waterborne
and acid-based materials
High flow version of 15D135
Instruction manuals
309834
309834
310696
310696
Technical Specifications and Ordering Information
