QT048
INTERCONNECTIONS
48/46 240 1 Ø 200 #6 to 300 mcm
48/46 208 3 Ø 175 #6 to 300 mcm
48/46 240 3 Ø 150 #6 to 300 mcm
48/46 480 3 Ø 80 #6 to 300 mcm
INSTALLATION LAYOUT
Installation Drawing Ref. No. 0G5868
Generac Power Systems, Inc. • P.O. Box 8, Waukesha, WI 53187 • generac.com
©2008 Generac Power Systems, Inc. All rights reserved. All specifications are subject to change without notice. Bulletin 0179270SBY/Printed in U.S.A. 09.08
WEIGHT: 1740 lbs.
