Kalatel CBR-PB3-WD 21 0150-0261A
8 Text to Camera Address
This section contains dipswitch settings for associating a
specific Cash Register’s transaction text with a specific
camera on the DVMRe unit.
SW1 - Dipswitches 5-8
Dipswitches 5 thru 8 on SW1 assigns transaction text for that cash register’s
PB3 unit to a specific camera on the DVMRe.
Legend: Off = (Up) On = (Down)
SW1
Dipswitch 5- 8
Camera Assignment
Dipswitch Numbers
Camera # 5 6 7 8
1 UP UP UP UP
2 UP UP UP DOWN
3 UP UP DOWN UP
4 UP UP DOWN DOWN
5 UP DOWN UP UP
6 UP DOWN UP DOWN
7 UP DOWN DOWN UP
8 UP DOWN DOWN DOWN
9 DOWN UP UP UP
10 DOWN UP UP DOWN
11 DOWN UP DOWN UP
