Installing Your Unit (cont.)
6. Review hopper contents to make sure all parts are available:
7. Fill out Warranty Registration Card with the requested information and mail to Grindmaster Corporation.
8. Replace side panels.
9. Assemble the dispense valve following the instructions on page 8. The valve plunger, spring and retaining pin
come in the small parts bag.
10. Be sure ON-OFF-CLEAN switches (toggle switch located underneath the electrical box) are in the “OFF” position.
11. Connect the power cord directly to a properly grounded DEDICATED 120V/60Hz, 20 Amp circuit or 220-240V/
50Hz, 15 Amp circuit for CE models. Do not use an extension cord.
12. Remove the drip tray kit from the bubble wrap. Separate the parts and remove the protective coating. The drip
tray is mounted on two screws that are located on the lower front of the freezer cabinet.
13. Place the key hole slot of the drip tray support bracket on to these screws and tighten the screws.
14. Angle the back of the drip tray surround bracket into the drip tray support bracket and lower bracket to lock it
into place.
15. Place drip tray onto drip tray surround bracket.
16. Place the louvered drip tray insert into drip tray.
Part # Description
W0600170 Manual
W0600073 Rubber Pad Sheet
W0600121 Merchandiser Installation Sheet
W0600012 MSDS Sanitizer Sheet
W0600159 Warranty Registration Card
W0890182 Drip Tray Kit
W0520093 Hopper Cover
W0480445 Valve Handle
W0631230 Valve Spring
* Carb Tube
* Dispense Valve Plunger
W0470076 Lubricant
W0631903 Sanitizer Packets
W0600058 Laminated Cleaning Instructions
W0600327 Seal Installation Instructions
* Optional items specified when the unit is ordered.
Model 3312 Page 5
CAUTION
Do not alter or deform the plug in any way! Altering or deforming the plug may damage unit and will void
warranty.
