Securing Child in Vehicle with
Shoulder Belt Positioning Clip
The shoulder belt MUST lay
across child’s shoulders in
red zone as shown.
If shoulder belt lays outside
this zone, the shoulder belt
positioning clip MUST be
used.
To attach clip to booster seat:
1. Insert the loop end of strap around bar on rear of
seat as shown in
. The shoulder belt positioning clip
MUST be attached onto the bar of the base closest to
where the vehicle shoulder belt lays across the child.
1
1
