ITEM DESCRIPTION PART NO. QTY. ITEM DESCRIPTION PART NO. QTY.
23
R e c r e a t i o n a l V e h i c l e G e n e r a t o r
1 Lower Bearing Carrier 75995 1
2 50 Rotor Assembly 92605G 1
3 50 Stator Assembly 92604G 1
4 Ball Bearing 73159 1
5 Ball Bearing 31971 1
6 Upper Bearing Carrier 72379 1
7 Stator Stud 77006 4
8 M8-1.25 Flange Lock Nut 52858 8
9 Brush Holder 66386 1
10 M5-0.8 x 16 Taptite 66849 2
11 Nylon Washer 27756 4
12 Generator Top Housing 86314 1
13 Resistor 75234 1
14 M6 Flat Washer 22473 3
15 M6 Lock Washer 22097 5
16 M6-1.0 x 60 Capscrew 74095 1
17 Ground Cable 90141 2
18 Shakeproof Lock Washer 22447 1
19 M6-1.0 x 20 Taptite 74906 4
20 P.C.B. Controller 94039 1
21 Starter Cable 10-74260 1
22 5/16 Lock Washer 22129 2
23 5/16-18 Hex Nut 22259 2
24 Panel Sheet Metal 86316 1
25 4-Pin Connector 53650 1
26 Connector 91915 1
27 Remote Harness 75244 1
28 M6-1.0 x 12mm Capscrew 66476 2
w/Lock Washer
29 Starter Contactor 86729 1
30 M4-0.7 x 16 Capscrew 75476 3
31 M4 Lock Washer 22264 4
32 Battery Charge Rectifier 65795 1
33 M3-0.5 x 15 Capscrew 90987 2
34 Panel Support Bracket 86317 1
35 M5-0.8 x 30 Capscrew 75235 3
36 Vibration Mount 82737 4
37 M6-1.0 Hex Nut 49813 4
38 M5-0.8 x 16 Capscrew 55440 1
39 M3 Lock Washer 43182 2
41 2.5A.-ON Circuit Breaker 53623 1
42 M5 Shakeproof Washer 22769 2
43 Regulator Voltage 83049 1
44 M5 Lock Washer 22152 6
45 M5-0.8 Hex Nut 51716 4
46 20A. Circuit Breaker 90144 1
47 30A All Units Cir. Breaker 90145 1
48 #6-32 w/Lockwasher Screw 25105 4
49 Panel Cover 86315 1
50 M4-0.7 x 16 Screw w/Lock 90734 4
Washer & Flat Washer
51 M4 Flat Washer 22985 1
52 Fuse Holder 32300 1
53 15A. AGC Fuse 22676 1
54 6A (Start/Stop) S.P.D.T. 87798 1
Switch
55 S.P.D.T. Switch (Fuel Pump) 92113 1
56 Terminal Block 75210A 1
57 M4 Shakeproof Washer 23365 1
58 M4-0.7 Hex Nut 51715 1
59 30A. CB Rating Decal 90157 1
60 20A. CB Rating Decal 90156 1
61 Cust. Connection Decal 89438A 1
62 Hose Clamp 31791 1
63 M5 Flat Washer 23365 1
64 M5 x 10 Taptite 74908 2
65 Bushing 23484S 1
66 Battery Cable Boot 75763A 1
67 Plastic Spacer 94070 1
68 M6-0.8 x 110 PPHMS. 94071 1
Generac NP-50LPG Recreational Vehicle Generator
REPAIR PARTS — ALTERNATOR AND PANEL Drawing No. 94106
