General description

Genelec 7060A, 7070A and 7071A are pow-

erful active subwoofers, incorporating all the

amplifi er and crossover electronics needed

for bass management and reproduction in

modern 6.1 or 5.1 channel surround sound

or traditional stereo systems. Their 19 to 120

Hz (±3 dB) (29 to 120 Hz on the 7060A) fre-

quency range, ample sound pressure capa-

bility and versatile connections make these

subwoofers ideal companions for Genelec's

active monitoring speakers.

Bass management unit

The built-in bass management unit has six

signal input and output channels (L/C/R Front

and L/C/R Rear), a discrete LFE signal input

and a summed signal output, providing great

fl exibility and easy connection in all monitor-

ing environments.

The active crossover contained in the bass

management unit splits the input signals into

low and high frequency components at 85

Hz. Frequencies below 85 Hz are directed to

the subwoofer and frequencies above 85 Hz

to the main speakers.

The low pass section sensitivity can be

adjusted from +12 dBu to -6 dBu to allow

easy subwoofer level matching with various

main speakers. All outputs have 0 dB pass-

band gain.

The low pass frequency of the LFE input

channel can be set to 85 Hz, 120 Hz or 85 Hz

with "Redirect" function that routes LFE con-

tent above 85 Hz to the front center monitor.

The input sensitivity of the LFE channel can

be set to 0 dB or +10 dB.

Balanced XLR connectors are used for the

system audio inputs and outputs.

Two "Bass Roll-Off" switches are included

to provide a fl at bass response in all acous-

tical environments, enabling adjustments of

the subwoofer response in three -2 dB steps.

Two phase matching switches in the crosso-

ver allow compensation for the delay which

occurs if the subwoofer is placed away from

the main speakers, or for other speaker sys-

tems phase behaviour. Four settings are pro-

vided between 0° and -270°. An 85 Hz test

tone generator is included to help achieve

accurate crossover phase alignment.

Installation

Each subwoofer is supplied with a mains cable

and an operating manual. Once unpacked,

place the subwoofer in a suitable location (for

more details see the "Positioning" section).

Before connecting the audio signals, ensure

that both the subwoofer and the main moni-

tors are switched off. Check that the voltage

selector switch is set according to your local

mains voltage (subwoofers sold in Europe

have a fi xed 230V setting). Connections are

easier to make if you roll the subwoofer on

its side with the amplifi er panel facing up. Use

this position only for making the connections

and roll the subwoofer back to its normal

upright position before use. Audio connec-

tions to the subwoofer are made via balanced

XLR connectors. An unbalanced source can

also be used with a special RCA to XLR

cable; the correct connection for the cable is

shown in Fig. 2. However, we recommend the

use of balanced cables and connectors due

to their better noise immunity. The connectors

are arranged in three rows on the amplifi er

panel (see Fig. 1):

Top row

LFE IN / SUM IN: Use this connector for

the LFE or .1 output channel of a 5.1- or

6.1-channel discrete surround sound source,

or the SUM OUT signal from the "master"

subwoofer in a daisy-chained multiple sub-

woofer confi guration. Note that the "sub-

woofer out" channel of an analogue matrix

surround decoder (Dolby Surround, Dolby
