12
DL (DUAL LINK) ONLY MODES
DL (Dual Link) Only Modes
The 8 DIP switch bank, located on the underside of the 8x1 DVI KVM DL
Switcher cab be used to set each individual input to work in a Dual Link Only
mode. These modes should only be enabled if issues occur when using Dual
Link sources and displays in the default mode.
DIP SWITCH Function DIP SWITCH Function
1 Input 1 Mode 5 Input 5 Mode
2 Input 2 Mode 6 Input 6 Mode
3 Input 3 Mode 7 Input 7 Mode
4 Input 4 Mode 8 Input 8 Mode
Use DIP switch 3 to set the desired EDID mode.
DL (Dual Link) and SL (Single Link) Mode (Switch=OFF) DEFAULT
• This setting can be set individually for each input. This mode will allow
the connection of both Dual Link and Single Link displays.
DL (Dual Link) Only Mode (Switch=ON)
• This setting can be set individually for each input. This mode should be
enabled if issues with the default occur with Dual Link displays.
