220v (prewired), 110v – Grizzly G0457 User Manual
Page 54
-52-
g0457 14" industrial Bandsaw (Mfg. Since 5/11)
READ ELECTRICAL SAFETY
ON PAGE 51!
PUSH BUTTON SWITCH
(viewed from behind)
START
STOP
220V (Prewired)
Start
Capacitor
300MFD
250VAC
Ground
4
3
2
1
110V
110V
220V
Ground
1
3
4
2
Hot
Hot
Hot
Ground
Neutral
Ground
5-20 Plug
(As Recommended)
6-15 Plug
(As Recommended)
220
VAC
G
Bl
Wt
Gn
Bl
Gn
Wt
Run
Capacitor
40MFD
250VAC
Bl
Wt
Gn
Bl
Wt
Gn
Bl
Wt
Gn
Bl
Wt Gn
Rewired to 110V
Rewired to 110V
figure 67. Motor wiring.
figure 68. push button switch wiring.
