Page 15
15
Care and Cleaning
Icemaker
Interior
1.
Unplug the icemaker or disconnect power.
2.
Open the storage bin door and remove any
ice that is in the bin.
3.
Remove the drain cap from the water pan
and drain thoroughly. Replace the drain
cap.
4.
Remove the three screws that hold the cutter
grid cover in place.
5.
Unplug the wiring harness from the left side
of the cutter grid.
6.
Unplug the ice level sensor from the right
side of the cutter grid. Pull the ice level
sensor down and forward away from the
cutter grid.
7.
Remove the right-hand screw and loosen the
left-hand screw. Lift the cutter grid up and
out over the left-hand screw.
NOTE:
Make sure the plastic spacer from the
right-hand side of the cutter grid bracket stays
with the cutter grid.
8.
Remove the two screws that hold the water
pan in place. Push down with one hand on
the front of the pan while pulling forward
on the bottom back side.
9.
The cutter grid, exterior of hoses, water pan,
storage bin, door gasket, and ice scoop
should be cleaned with mild soap or
detergent and warm water. Rinse in clean
water. Then clean the same parts with a
solution of 1 tablespoon (15 mL) of
household bleach in 1 gallon (3.8 L)
warm water. Rinse again thoroughly in
clean water.
NOTE:
Do not remove hoses. Do not wash
plastic parts in dishwasher. They cannot
withstand high temperatures.
10.
Wash only the outside of the plastic hoses
with mild soap or detergent and warm
water. Rinse with clean water.
11.
Replace water pan by pushing back on the
bottom with one hand while pushing up
and back on the top. Secure the water pan
by replacing both screws.
12.
Check the following:
•
Drain cap from the water pan is in place.
•
Hose from the water pan is inserted into
the storage bin drain opening.
13.
Slide the cutter grid back into place and
secure it by replacing the right-hand screw
and tightening the left-hand screw.
Reconnect the electrical and ice level
sensor harnesses.
14.
Replace the cutter grid cover with three
screws.
15.
Plug in the icemaker or reconnect power.
16.
Reset the controls. See the “Set controls”
section.
Cutter
grid
cover
OFF
ON
CLEAN
Screws
Wiring
harness
Cutter
grid
Ice level
sensor
Screw
Plastic
spacer
Screw
