6
1.
Orient the the Front Stabilizer (35) as shown.
Attach the two Wheels (25) to the Front
Stabilizer with two M10 x 62mm Bolts (89) and
two M10 Nylon Locknuts (97).
Attach two Leveling Feet (26) to the underside
of the Front Stabilizer (35).
2. Have a second person tip the Frame (2) back-
ward. Attach the Front Stabilizer (35) to the
Frame with two M10 x 78mm Button Screws
(90).
97
26
26
1
2
89
89
25
25
90
35
35
2
3. Position the Base (1) near the Frame (2) as
shown. See the inset drawing. Attach two
Leveling Feet (26) to the underside of the Base.
Have a second person tip the Frame (2) for-
ward. Insert the Base (1) into the Frame. Attach
the Base with four M8 x 75mm Button Screws
(107), four M8 Split Washers (72), and four
M8 x 15mm x 4.5mm Washers (99).
2
1
3
1
99
72
107 107
26
26
To make assembly easier, read the
information on page 5 before you begin
assembling the elliptical exerciser.
72
99
