Grizzly Cordless LED H7517 - Manual

Introduction
The Model H7517 Cordless Rechargeable LED
Work Light (
Figure 1) features a retractable hook,
30 LEDs that stay lit 5 to 6 hours on each charge,
and a water-resistant body.
Inventory
A. Work Light .................................................. 1
B. Charger ...................................................... 1
C. Cord ............................................................ 1
Assembly and Operation
1. Attach the cord to the charger.
2. Place the work light into the charger and
charge for 6-8 hours before the first use. An
indicator light on the charger glows red dur-
ing charging.
Note—If the indicator light does not illumi-
nate, make sure the work light and charger
contact. Be sure the work light is OFF before
charging.
3. Remove the work light from the charger when
the indicator light turns green, showing it is
fully charged. Recharge the work light when
the bottom warning LED turns red.
Note—After the warning LED illuminates,
the work light will stay lit for several seconds
before shutting off.
4. Charge the work light in the charger for three
hours after the warning LED illuminates. Fully
charge the light before storing.
If you need additional help with this assembly, call
our service department at: (570) 546-9663.
CORDLESS LED
WORK LIGHT
MODEL H7517
INSTRUCTION SHEET
Figure 1. Model H7517.
Work light is water resistant, but not water-
proof. Unit may be damaged if submerged
in water.
Keep away from fire! Work light could
explode!
NOTICE
