G0501 Sliding Table Saw -71-
G0501 Swinging Arm Assembly
REF PART # DESCRIPTION REF PART # DESCRIPTION
616 PLW04M LOCK WASHER 8MM
617 PW01M FLAT WASHER 8MM
618 PR37M EXT RETAINING RING 32MM
619 P6002 BALL BEARING 6002
620 P05010620 PLASTIC ROLLER
621 P05010621 CAM
622 PW01M FLAT WASHER 8MM
623 PB20M HEX BOLT M8-1.25 X 35
624 PB09M HEX BOLT M8-1.25 X 20
625 PR05M EXT RETAINING RING 15MM
626 P6202 BALL BEARING 6202
627 P05010627 GUIDE ROLLER
628 P05010628 AXIS
629 P05010629 SWINGING ARM
601 P05010601 CLEANING BRUSH
602 PSB04M CAP SCREW M6-1.0 X 10
603 PW03M FLAT WASHER 6MM
604 PW02M FLAT WASHER 5MM
605 PHTEK23 TAP SCREW #10 X 1/2"
606 P05010606 BRUSH COVER
607 P05010607 STOP
608 PN28M HEX NUT M20-2.5
609 P05010609 TELESCOPING TUBE
610 P05010610 SUPPORT BOLT
611 PW13M FLAT WASHER 20MM
612 P05010612 TOP ARM BOLT
613 P6203 BALL BEARING 6203
614 P05010614 BOTTOM ARM BOLT
615 PN03M HEX NUT M8-1.25
