Generac Power Systems 005223-0 User Manual
Page 39
1
0F1823A
1
ENCL HSB CONTROL PANEL
2
0F3078
1
COVER CONTROL PANEL
3
0F2606
1
HINGE CONTINUOUS H-PNL
4
036261
6
RIVET POP .125 X .275 SS
5
0F2627A
1
COVER CONTROL PANEL SIDE
6
043181
4
SCREW PHM M3-0.5 X 10MM
7
052777
7
WASHER FLAT M3
8
0F4245A
1
AASY PCB COMM CTRLR 1800 RPM
9 *
0F1262
4
HOLDER FUSE WICKMANN 178.6150
10 *
0F1263
1
ADPTR RH SIDE WICKMAN 178.6191
11 *
0F1264
1
ADPTR LH SIDE WICKMAN 178.6192
12
0F1725C
1
ASSY PCB 2AMP 12V UL BATT CHGR
13
067680
1
ASSY VOLTAGE REGULATOR 60HZ
14
0E6875A
2
RELAY 12VDC C FORM W/DIODE
15 *
055911
1
BLOCK TERM 20A 12 X 6 X 1100V
16
056739
1
RELAY SOLENOID 12VDC PNL MNT
17
0E3161
1
ASSY PCB BOSCH GOV DRIVER
18
0F5459
1
DECAL CPL CONTROL PANEL FUSES
19
0F5462
1
DECAL CPL 3.9L TB1
20
0A5062J
4
SPACER 9.5H 3.2 ID
22
029673
1
DIO BRIDGE 25A 600V
23
048467
1
CIRCT BRK 7 X 1 ETA 46-500-P
24
0F1958
1
PLATE HARNESS CLAMP
25
082573
1
SWITCH RKR DPST 125V SPD
26
0E4494
1
SWITCH RKR DPDT ON-OFF-ON
27
0F3215
1
DECAL CONTROL HSB
30
0F5886
7
SCREW HHPM M5-0.8 X 12
31
051713
16
WASHER FLAT M5
32
049226
16
WASHER LOCK M5
33
0F5752F
1
RES WW 15R 5% 25W QK CONN
34
0F5884
2
SCREW PHTT M3.5-0.6 X 10
37
0F5896
2
SCREW PHTT M3.5-0.6 X 16
38
0C2265
4
SCREW PHTT M4-0.7 X 12 ZYC
39
0C3990
2
SCREW PHTT M4-0.7 X 10 ZYC
40
091525
4
SCREW PPHM M4-0.7 X 6 ZINC
41
051716
9
NUT HEX M5-0.8 G8 CLEAR ZINC
42
079224
2
SCREW PPHM M5-0.8 X 30 SS
43
022287
2
SCREW HHC 1/4-20 X 3/4 G5
44
022473
4
WASHER FLAT 1/4-M6 ZINC
45
022097
2
WASHER LOCK M6-1/4
46
022127
2
NUT HEX 1/4-20 STEEL
47
0F6305
2
SEAL COVER 3.18X12.7X382
48
0F6305A
1
SEAL COVER 3.18X12.7X283
49
0F6145
A/R
SEAL WEATHER .45"DIA
50
091526
4
SCREW PPHM M5-0.8 X 12 ZNC
51
043182
7
WASHER LOCK M3
52
051714
7
NUT HEX M3-0.5 G8 YEL CHR
58
0F3192
1
SUPPORT ANGLE PCB
60
0E7403C
1
FUSE ATO TYPE 15 AMP (BLUE)
61
0F4416
1
HARN 1800RPM R-100 CONTROL PNL (NOT SHOWN)
* PART OF WIRE HARNESS
