5
(22)LSB/USB Button
- To select the lower or upper side band on SSB (Single
iSide Band) reception.
Stepping button, steps forward in the order:
With reception frequency < 10 MHz = LSB Æ USB Æ
Normal Æ LSB, etc.
With reception frequency ≥10 MHz = USB Æ LSB Æ
Normal Æ USB, etc.
LSB = Lower Side Band;
USB = Upper Side Band.
On FM:
Keep pressed button = indication of the RDS quality
(23) STORE Button
- For storing the displayed frequency or the station
name and the selected reception mode (e.g., Mc Stereo,
LSB/USB) into one of the station memory locations 1 ...
40.
Press briefly: Store compare.
- Indication whether the frequency tuned to has ready
been stored (e.g., ＊MEMO 3 ... MEMO5 …
MEMO8 ... ).
- Further pressures on the button or keeping it press
indicates whether the respective frequency is stored
several times and, if so, on which location numbers.
- If the frequency is not yet stored, the display (4)
indicate ＊ NEW.
Press a longer time:
- Indication of all free memory locations
(e.g., ＊ FREE 6 ... FREE 8 ... FREE 25 ... ).
(24) A - Z Button
- To enter the abbreviation for the currently selected
station memory location.
(25) SOUND (NORMAL -BOOST)
not on headphone operation.
NORMAL = normal output power
(low-current drain on battery operation);
BOOST= the output power is more than
doubled(recommended on mains unit operation).
(26)TONE (MUSIC - SPEECH)
MUSIC = normal reproduction;
SPEECH = speech reproduction.
(27) Headphone Jack (Ω)
- For stereo headphones with 3.5 mm jack plug and an
impedance of 32-2000Ω.
FM stereo reception is only possible with a headphone.
When connecting a headphone, the built-in loud-
speaker is automatically disconnected.
(28) 3.5 mm Output Socket (LINE OUT)
- High-level output for making recordings.
( 2 9 ) 3.5 mm Output Switch Jack (
)
- For controlling external units (e.g., a tape deck).
(30) 3.5 mm Coaxial Socket (DC IN 9V
)
- For connecting the mains unit accompanying the unit (AC
adapter NR 90-1).
